6.9 For Serviceman
OPERATION PARAMETER #00
OPERATE MODE COOL
ADDRESS
SV1 STATE ON
The power consumption parameter is optional. If some parameter
is not be activated in the system, the parameter will show "--"
The heat pump capacity is for reference only, not used to judge
the ability of the unit. The accuracy of sensor is ±1℃. The flow
rates parameters are calculated according to the pump running
parameters,the deviation is different at different flow rates,the
maximum of deviation is 15%.The flow parameters are calculated
according to the electrical parameters of the pump operation.
The operating voltage is different and the deviation is different.
The display value is 0 when the voltage is less than 198V.
INFORMATION
i
6.9.1 About For Serviceman
FOR SERVICEMAN is used for installater and service
engineer.
Setting the function of equipment.
Setting the parameters.
6.9.2 How To Go To For Serviceman
Go to '' '' > ''FOR SERVICEMAN''. Press '' ''.
ONLINE UNITS NUMBER 1
SV2 STATE OFF
SV3 STATE OFF
PUMP_I ON
1/9
OPERATION PARAMETER
#00
PUMP_C OFF
ADDRESS
PUMP_S OFF
PUMP_O OFF
PUMP_D OFF
PIPE BACKUP HEATER OFF
TANK BACKUP HEATER ON
2/9
OPERATION PARAMETER
#00
T1 LEAVING WATER TEMP. 35°C
ADDRESS
WATER FLOW 1.72m
3 /h
GAS BOILER OFF
HEAT PUMP CAPACTIY 11.52kW
POWER CONSUM 1000kWh
Ta ROOM TEMP. 25°C
3/9
OPERATION PARAMETER
#00
Tw2 CIRCUIT2 WATER TEMP. 35°C
ADDRESS
TIS’ C1 CLI. CURVE TEMP. 35°C
T5 WATER TANK TEMP. 53°C
TIS2’ C2 CLI. CURVE TEMP. 35°C
TW_O PLATE W-OUTLET TEMP. 35°C
TW_I PLATE W-INLET TEMP. 30°C
4/9
OPERATION PARAMETER
#00
Tbt2 BUFFERTANK_LOW TEMP. 35°C
ADDRESS
IDU SOFTWARE 01-09-2019V01
Tbt1 BUFFERTANK_UP TEMP. 35°C
5/9
OPERATION PARAMETER
#00-
COMP.CURRENT 12A
ADDRESS
COMP.FREQENCY 24Hz
ODU MODEL 6kW
COMP.RUN TIME 54 MIN
COMP.TOTAL RUN TIME 1000Hrs
EXPANSION VALVE 200P
6/9
OPERATION PARAMETER
#00
IDU TARGET FREQUENCY 46Hz
ADDRESS
FREQUENCY LIMITED TYPE 5
FAN SPEED 600R/MIN
SUPPLY VOLTAGE 230V
DC GENERATRIX VOLTAGE 420V
DC GENERATRIX CURRENT 18A
7/9
OPERATION PARAMETER
#00
TW_I PLATE W-INLET TEMP. 30°C
ADDRESS
T2 PLATE F-OUT TEMP. 35°C
TW_O PLATE W-OUTLET TEMP. 35°C
T2B PLATE F-IN TEMP. 35°C
Th COMP. SUCTION TEMP. 5°C
Tp COMP. DISCHARGE TEMP. 75°C
8/9
OPERATION PARAMETER
#00
T4 OUTDOOR AIR TEMP. 5°C
ADDRESS
TF MODULE TEMP. 55°C
T3 OUTDOOR EXCHARGE TEMP. 5°C
P1 COMP. PRESSURE 2300kPa
ODU SOFTWARE 01-09-2018V01
HMI SOFTWARE 01-09-2018V01
9/9
Tsolar 25°C
Please input password:
2 3 4
ENTER
FOR SERVICEMAN
ADJUST
