Airxcel 45000 Series User Manual

5
FIGURE 7
FIGURE 8
REFER TO OEM DUCTING REQUIREMENTS FOR SUPPLY AND RETURN DUCTING INFORMATION.
OEM DUCTING REQUIREMENT DOCUMENT IS AVAILABLE AT www.AIRXCEL.com.
IT IS THE RESPONSIBILITY OF THE INSTALLER TO PROVIDE THE MEANS FOR SEGREGATION OF
SUPPLY AND RETURN AIR.
1.08
16.15
1.98
16.94
.47
13.06
REAR BASE PADS
DIMENSIONS FROM 14"x14" ROOF OPENING
TO INSTALLER PROVIDED MOUNTING SCREWS.
RETURN AIR
SUPPLY AIR
INSTALLER SUPPLIED
MOUNTING BOLTS
FIGURE 5
FIGURE 6
