8
ROOFTOP UNIT
ROOF STRUCTURE
MOUNTING FRAME
DUCT COLLAR
CEILING
ASSEMBLY
CHUTE
FABRIC DUCT
MATERIAL
CEILING
ASSEMBLY
SHROUD
CONTROL
KNOBS
GRILLES
FILTERS
FIGURE 11
