AIS DiVi Installation Instructions (P-DVINSTRUCT01)
Slide the 20 7/8 inch long
hinge down into hinge channel
of the high panel.
Slide the 20 7/8 inch long
hinge down into hinge channel
of the high panel down to the
top of the low panel.
Repeat same process for
second piece of hinge. Choose
correct length using table at
page 2 and the height of the
short panel.
