AIS Matrix - Electrical Powerways Installation

12345
Matrix 2019
www.ais-inc.comwww.ais-inc.com
11
P-MXINSTRUCT01 Rev 07.29.2020
Electrical - Powerways
#8-32 x 5/16”
Pan Head Machine Screw
Philips Drive #2
4 places
Required hardware:
#8-32 x 5/16” Pan Head
Machine Screw
#RP-MXHS83214
Use philips drive #2
4 places
Align powerway mounting
holes to mounting holes in
vertical frame
Upper position holes
Lower position holes
