AIS Matrix - Electrical Jumpers Installation; Connecting Electrical Jumpers

12345
Matrix 2019
www.ais-inc.comwww.ais-inc.com
12
P-MXINSTRUCT01 Rev 07.29.2020
Electrical - Jumpers
Fully Engage Locking Clip
Plug Jumper into Powerways
Double Powerway
Vertical Jumper
(fiberglass mesh)
Panel-To-Panel Jumper (fiberglass mesh)
Feed Jumpers through
electrical chase holes
Vertical Transition Jumper
Lateral Pass Through Jumper
(metal flex cable)
Engage clip HERE
Note UP arrow
Powerway mounted
in upper location
