4
Installation
Typically, 3GDA installation consists of the following:
1.
Connect video equipment to the BNCs
2.
Apply +5-18VDC power to the converter (AJA power supply model DWP or
DWP-U)
Specifications
Item Specification
Input 1 HD-SDI, SDI (SMPTE 259/292/296/424), 1x BNC
Formats 3Gb, 1.5Gb, 270Mb Auto Select
Outputs 3G HD-SDI, HD-SDI, SDI, 6x BNC,
Equalizing and re-clocking
Cable Equalization 270mb, 350m
1.5Gb, 200m
3Gb, 120m
Cable Equalization (1694 coax)
Input/Output Return Loss >15db, 270Mb - 3Gb
Power
(AJA power supply model DWP or
DWP-U)
+5-18VDC, Regulated, 3 watts
Size 5.8” x 2.4” x 1” (131 x 61 x 25mm)
