AJA 3GM - Appendix A: Specifications; Video; Audio; User Controls

3GM v1.5 www.aja.com
7
Appendix A: Specifications
Video
Input SDI - 3G/HD/SD-SDI, SMPTE-259/292/296/424/425, 2x BNC
Formats 3Gb, 1.5Gb, 270Mb Auto Select
See Tab le 2, “3GM Video Format Support,” on page 8 for details.
Output SDI - 3G/HD/SD-SDI, SMPTE-259/292/296/424/425, 3x BNC
Cable Equalization (1694 coax)
• 270mb, 350m
• 1.5Gb, 200m
• 3Gb, 120m
Input/Output Return Loss >15db, 270Mb - 3Gb
Audio
Input Up to 32-channel embedded SDI audio input
• (3G-A, HD, SD only 16-ch supported)
Output Up to 32-channel embedded SDI audio output
• (3G-A, HD, SD only 16-ch supported)
User Controls
External DIP switch
Physical
Size 4.6" x 2.4" x 1" (117 x 61 x 25 mm)
Power Uses AJA Power Supply model DWP-U-R1 (included)
100-240V, 50/60Hz Universal Input
+5V DC regulated, 7.5 watt capacity
NOTE: 3GM is not recommended for use with AJA DRM chassis rackmount kit.
