MPD16 (BOM)
Lvl Materials SPECS Qt
Part Location
.1 AL7-10-0144-C
SENSOR LARGE 16-KEY FSR SENSOR REV.3
1
8
.1 AL9-15-0423
KNOB SLIDE(ADD BLACK INK)
6
1
..2 PT1510602
KNOB SLIDE
1
.1 AL9-30-0045
SILICON KEY PAD
1
4
.1 BAGL-70L
WIRE CLIP
2
29
.1 BAOD6ID3T03
FIBER WASHER (BLUE)
4
38
.1 BAPR-03T
RIVET
2
7
.1 EVA1304408
SHIELD LCD EVA
2
5
.1 EVA1304432
EVA (20X20X2MM)
1
31
.1 FFC1810002001
18P FLAT WIRE 200MM FFC
1
22
.1 LAC22AKA67
BARCODE & SERIAL NO LABEL AD26
3
35
.1 LAC42YAH298
WEEE LABEL
1
35
.1 LAC52ALE01
LABEL (SAFETY)
1
3
.1 LAC67AKA93
DOUBLE SIDE TAPE AD26
1
37
.1 LAC67MAR195
ADHESIVE TAPE NITTO 500 (68MMX5MM)
2
17
.1 LAC67MAR196
ADHESIVE TAPE NITTO 500 (50MMX7MM)
2
18
.1 MT1504407
FIXED HOLDER (L)
2
27
.1 MT1504408
FIXED BASE
1
12
.1 MT1504409
FIXED HOLDER (R)
1
11
.1 MT153030102
BOTTOM PLATE(SPRAY&PRINT) AD26
1
13
.1 PT1501404
LCD SCREEN
1
19
.1 PT1510619
PUSH BUTTON
18
23
.1 PT1510651
BUTTON (LARGE)
3
32
.1 PT153001401
TOP PANEL(SPRAY/PRINT) AD26
1
2
..2 PT1530014
TOP PANEL (R) AD26
1
.1 RU1330701
RUBBER FOOT
4
25
.1 RU1504304
FOOT CUSHION
1
10
.1 RU1504305
FOOT CUSHION
2
26
.1 SC0208RBBI
SCREW
4
24
.1 SC0308RBBI
SCREW
26
9
.1 SC0308RIBI
SCREW
12
14
.1 TWLCM-WTDH002
MPD24 LCD ASS'Y
1
21
..2 CN0100000503
1P EARTH WIRE
1
..2 LCM-WTDH002
LCD
1
.1 UHA5FS233X3X12
CORE 45 O 100MHZ 23.3*3*12MM
1
36
.1 UHRI28X75X18
EMI COIL
1
30
.1 WS073307IC
WASHER
2
28
.1 WS083205P
WASHER
1
33
.1 TWPC09A00701
PCB ASS'Y
1
..2 PC09A007
P.C.BOARD (MAIN) AD26
1
..2 TWPC09A007A01
MAIN PCB ASS'Y
AD26
1
6
...3 SWEVQ11L05R
TACT SWITCH (5MM) ROUND TERMINAL
21
S1~21
...3 AL0-16-1009
CHIP RES. 10 OHM,1/8W, -+1%, 0805
1
R81
...3 AL0-17-0101
CHIP RES.4X100 OHM 1/16W 5% C-C=0.8MM
6
R56, 78~80, 86, 87
...3 AL1-51-0475
CAP 4.7UF X5R 1206 10% 16V
6
C17, 41, 45, 57, 70, 71
...3 AL2-51-4401
TRANS NPN 2N4401 40V 1A SOT-23
2
Q8, 9
...3 AL2-51-4403
TRANSISTOR PNP 2N4403 40V 800MA SOT-23
2
Q6, 7
...3 AL2-62-0014
I.C. 74AHC14
1
U5
...3 AL2-71-1324
IC LMV324M SOT-14
1
U6
...3 AL2-73-4051
IC 74HC4051 SINGLE 8-CHAN MUX 16-PIN SOIC
3
U3, 7, 9
...3 CS102J5005COG
CHIP CAP 1000PF/50V ±5% 0805 (NPO)
3
C77~79
...3 CS103K5003X7R
C.CAP 0.010UF 50V X7R,±10% SMD 0603
9
C38, 39, 42, 46, 50, 51, 53, 54, 69
...3 CS104K5003X7R
CHIP CAP 0.1UF/50V,X7R,+/-10%, SMD 0603
60
C1~6, 10~16, C31~36, 43, 44, 47, 52,
C58~66, 72~76, 84~106
...3 CS180J5003COG
C.CAP 18PF 50V 0603 SMD
2
C67, 68
...3 CS561J5005COG
CAP. 560PF NPO
4
C48, 49, 55, 56
...3 DIBAV70
DIODE BAV70 SOT-23
20
D5~24
...3 ICSTM32F102RBT6
IC STM32F102RBT6 TQFP-64
1
U8
...3 RS000008J05
CHIP RES. 0 Ω[ 5% SMD 0805
1
R84
...3 RS000108J05
CHIP RES. 1 Ω 5% SMD 0805
1
R13
