Lvl Materials SPECS Qt
Part Location
...3 RS001M08F05
CHIP RES. 1M Ω 1% SMD 0805
3
R11, 76, 95
...3 RS002208F05
CHIP RES. 22 Ω 1% SMD 0805
2
R82, 83
...3 RS004708F05
CHIP RES. 47 Ω 1% SMD 0805
1
R85
...3 RS010K10F03 CHIP RES. 10K Ω 1% SMD 0603 21
R36, 37, 40~47, 50~52, 54, 58, 59, 64,
65, R74, 75, 98
...3 RS022010F03
CHIP RES. 220 Ω 1% SMD 0603
3
R77, 94, 96
...3 RS027K08F05
CHIP RES. 27K Ω 1% SMD 0805
4
R67, 68, 71, 72
...3 RS033K10F03
CHIP RES. 33K Ω 1% SMD 0603
1
R62
...3 RS047008F05
CHIP RES. 470 Ω 1% SMD 0805
5
R63, 66, 69, 70, 73
...3 RS04K708F05
CHIP RES. 4.7K Ω 1% SMD 0805
4
R48, 49, 88, 89
...3 RS100K08F05
CHIP RES. 100K Ω 1% SMD 0805
2
R60, 61
...3 XTM08000X6F1
Crystal 8MHz HC49SMD
1
X1
...3 AA821842X
SOCKET 20FMZ-ST 20P
1
J7
...3 AL0-09-0044
VARIABLE RESISTOR 2.5KB
6
R53, 55, 90, 91, 93, 97
...3 AL0-09-0057
SLIDE VR (STEREO) 10KB 45MM
6
R8~10, 12, 14, 15
...3 AL3-02-0036
LED (AMBER)
2
LED1, 2
...3 BALE48207-5A
LED HOLDER 7.5MM HEIGHT 2.54 PITCH
2
(LED1, 2)
...3 CN1425403001
14P FLAT WIRE 300MM
1
J9
...3 FCN1R1001801
FPC CONNECTOR 18P
1
J10
...3 NM1106112
VELVET CARPET
6
...3 SWDC11B20214A6
ENCODER 20 DETENT PRESS SWITCH
1
E1
...3 TE952542001
DUAL CONNECTOR 20P 2.54MM 90DEG
1
J8
...3 WR112830032G1
5P CONNECTOR WIRE (USB) 300MM
1
J11
..2 TWPC09A007B01
I/O PCB ASS'Y
AD26
1
20
...3 AL1-51-0475
CAP 4.7UF X5R 1206 10% 16V
1
C23
...3 AL2-51-0140
DIODE POWER SCHOTTKY MBRS140LT3 40V 1A
2
D2, 3
...3 AL2-51-4401
TRANS NPN 2N4401 40V 1A SOT-23
3
Q2, 3, 5
...3 AL2-51-4403
TRANSISTOR PNP 2N4403 40V 800MA SOT-23
2
Q1, 4
...3 AL2-52-5242
DIODE ZENER MMBZ5242B 12V SOT-23
1
D1
...3 AL2-54-6306
TRANS SMALL-SIGNAL DUAL EN-MOSFET FDC6306P SSOT-6
1
U1
...3 AL2-61-7223
IC REG VOLTAGE NJU7223DL1-33 3.3V TO-252
1
U2
...3 AL2-74-0181
IC OPTO ISOLATOR TLP181 TRANS-OUT (SMD)
1
U4
...3 CS102J5005COG
CHIP CAP 1000PF/50V ±5% 0805 (NPO)
4
C26, 27, 29, 30
...3 CS104K5003X7R
CHIP CAP 0.1UF/50V,X7R,+/-10%, SMD 0603
7
C8, 9, 22, 24, 25, 28, 40
...3 CS105K1003X5R
CERAMIC CAP 1UF 10V X5R 0603
3
C7, 19, 20
...3 DIBAV70
DIODE BAV70 SOT-23
1
D4
...3 RS000008J05
CHIP RES. 0 Ω[ 5% SMD 0805
11
R5, 7, 18, 24, 26~28, 33~35, 38
...3 RS001K10F03
CHIP RES. 1K Ω 1% SMD 0603
3
R2~4
...3 RS004708F05
CHIP RES. 47 Ω 1% SMD 0805
1
R25
...3 RS010K10F03
CHIP RES. 10K Ω 1% SMD 0603
5
R6, 16, 17, 20, 29
...3 RS01K510F03
CHIP RES. 1.5K Ω 1% SMD 0603
1
R23
...3 RS022010F03
CHIP RES. 220 Ω 1% SMD 0603
3
R30~32
...3 RS047K10F03
CHIP RES. 47K Ω 1% SMD 0603
2
R19, 22
...3 RS056K10F03
CHIP RES. 56K Ω 1% SMD 0603
1
R21
...3 RS820K10F03
CHIP RES. 820K Ω 1% SMD 0603
1
R1
...3 UHLPF3218MF100M
INDUCTOR 10UH 1A 0.29O SMD-ROHS
2
L1, 2
...3 AL4-00-0002
JACK DIN 5 PIN MIDI PCB MOUNT 180°W/SHIELD SOCKET
2
J5, 6
...3 AL4-08-0402
CON USB SOCKET 4 PIN FEMALE PC-MNT HORIZONTAL
1
J4
...3 EC10710TS
E. CAPACITOR 100UF/10V 7MM
1
C21
...3 JKDJ-0702B-020
DC SOCKET 2.0MM
1
J3
...3 PT1304702
INSULATOR SHEET
2
(J5, 6)
...3 TE10200502
5P CONNECTOR SOCKET 180°
1
J2
...3 TE962541401
14P CONNECTOR SOCKET
1
J1
.1 TWPT151062001
PLASTIC KNOB ASS'Y (KNOB + COVER)
7
..2 PT1510620
KNOB
1
15
..2 PT1510621
KNOB COVER
1
16
.1 AA406633J
PE BAG 370X280X.03 PRINTING
0.006
.1 AA821535X
CORD USB A-B L1000 BLACK
1
.1 AL7-51-0226-E
AKAI SAFETY MANUAL REV.E
1
.1 AL9-63-0010-A
AD32 ABLETON LIVE LITE 7 CD
1
.1 AL9-63-0017
MPD26 CD
1
