18
MAIN BOARD PARTS LIST
RESISTOR
R47 QCF015030-2200 22 OHM 1/10W 5% 0603
R48 QCF015030-4730 47K OHM 1/10W 5% 0603
R49 QCF015030-2200 22 OHM 1/10W 5% 0603
R50 QCF015030-2200 22 OHM 1/10W 5% 0603
R500 QCF015030-4700 47 OHM 1/10W 5% 0603
R503 QCF015030-4730 47K OHM 1/10W 5% 0603
R504 QCF015030-4720 4.7K OHM 1/10W 5% 0603
R51 QCF015030-1020 1K OHM 1/10W 5% 0603
R510 QCF015030-4720 4.7K OHM 1/10W 5% 0603
R512 QCF015030-0000 0 OHM 1/10W 5% 0603
R513 QCF015030-0000 0 OHM 1/10W 5% 0603
R516 QCF015030-1820 1.8K OHM 1/10W 5% 0603
R517 QCF015030-1050 1M OHM 1/10W 5% 0603
R519 QCF085020-1010 100 OHM 1/8W 5% 0805
R52 QCF015030-1020 1K OHM 1/10W 5% 0603
R520 QCF015030-2220 2.2K OHM 1/10W 5% 0603
R521 QCF015030-2220 2.2K OHM 1/10W 5% 0603
R522 QCF085020-1010 100 OHM 1/8W 5% 0805
R523 QCF015030-3320 3.3K OHM 1/10W 5% 0603
R524 QCF015030-1040 100K OHM 1/10W 5% 0603
R526 QCF015030-3320 3.3K OHM 1/10W 5% 0603
R527 QCF015030-2220 2.2K OHM 1/10W 5% 0603
R528 QCF015030-2220 2.2K OHM 1/10W 5% 0603
R529 QCF015030-0000 0 OHM 1/10W 5% 0603
R530 QCF015030-0000 0 OHM 1/10W 5% 0603
R531 QCF015030-0000 0 OHM 1/10W 5% 0603
R532 QCF015030-0000 0 OHM 1/10W 5% 0603
R533 QCF015030-1030 10K OHM 1/10W 5% 0603
R534 QCF015030-2220 2.2K OHM 1/10W 5% 0603
R535 QCF011030-2200 220 OHM 1/10W 1% 0603
R536 QCF011030-1200 120 OHM 1/10W 1% 0603
R537 QCF015030-0000 0 OHM 1/10W 5% 0603
R538 QCF015030-0000 0 OHM 1/10W 5% 0603
R539 QCF015030-0000 0 OHM 1/10W 5% 0603
R56 QCF015030-4720 4.7K OHM 1/10W 5% 0603
R57 QCF015030-4710 470 OHM 1/10W 5% 0603
R58 QCF015030-4720 4.7K OHM 1/10W 5% 0603
R59 QCF015030-4730 47K OHM 1/10W 5% 0603
R61 QCF015030-7500 75 OHM 1/10W 5% 0603
R62 QCF015030-7500 75 OHM 1/10W 5% 0603
R64 QCF015030-7500 75 OHM 1/10W 5% 0603
R65 QCF015030-7500 75 OHM 1/10W 5% 0603
R67 QCF015030-7500 75 OHM 1/10W 5% 0603
R68 QCF015030-7500 75 OHM 1/10W 5% 0603
R70 QCF015030-3320 3.3K OHM 1/10W 5% 0603
R71 QCF015030-2200 22 OHM 1/10W 5% 0603
R72 QCF015030-2200 22 OHM 1/10W 5% 0603
R73 QCF015030-2200 22 OHM 1/10W 5% 0603
R74 QCF015030-7500 75 OHM 1/10W 5% 0603
RESISTOR
R75 QCF015030-7500 75 OHM 1/10W 5% 0603
R76 QCF015030-7500 75 OHM 1/10W 5% 0603
R77 QCF015030-7500 75 OHM 1/10W 5% 0603
R78 QCF015030-7500 75 OHM 1/10W 5% 0603
R79 QCF015030-7500 75 OHM 1/10W 5% 0603
R80 QCF015030-7500 75 OHM 1/10W 5% 0603
R81 QCF015030-7500 75 OHM 1/10W 5% 0603
R82 QCF015030-7500 75 OHM 1/10W 5% 0603
R83 QCF015030-1050 1M OHM 1/10W 5% 0603
R84 QCF015030-1010 100 OHM 1/10W 5% 0603
R85 QCF015030-4730 47K OHM 1/10W 5% 0603
R86 QCF015030-1020 1K OHM 1/10W 5% 0603
R87 QCF015030-1050 1M OHM 1/10W 5% 0603
R88 QCF015030-1010 100 OHM 1/10W 5% 0603
R89 QCF015030-4730 47K OHM 1/10W 5% 0603
R9 QCF015030-4730 47K OHM 1/10W 5% 0603
R90 QCF015030-1020 1K OHM 1/10W 5% 0603
RP1 QCA165340-0000 0 OHM 1/16W 5% 0603 8P4R
RP16 QCA165340-4720 4.7K OHM 1/16W 5% 0603
RP2 QCA165340-0000 0 OHM 1/16W 5% 0603 8P4R
RP3 QCA165340-3300 33 OHM 1/16W 5% 0603 8P4
R
RP4 QCA165340-3300 33 OHM 1/16W 5% 0603 8P4
R
RP5 QCA165340-3300 33 OHM 1/16W 5% 0603 8P4
R
RP6 QCA165340-3300 33 OHM 1/16W 5% 0603 8P4
R
RP7 QCA165340-3300 33 OHM 1/16W 5% 0603 8P4
R
RP8 QCA165340-3300 33 OHM 1/16W 5% 0603 8P4
R
RP9 QCA165340-4720 4.7K OHM 1/16W 5% 0603
CAPACITOR
C1 PXL439670-1040 0.1uF 50V +80% -20%
C10 PBE039542-1011 CHIP VER 100 uF 16V 20%
C100 PXL439670-1040 0.1uF 50V +80% -20%
C101 PXL439670-1040 0.1uF 50V +80% -20%
C102 PXL439670-1040 0.1uF 50V +80% -20%
C103 PXL439670-1040 0.1uF 50V +80% -20%
C104 PXL439670-1040 0.1uF 50V +80% -20%
C105 PXL439670-1040 0.1uF 50V +80% -20%
C106 PXL439670-1040 0.1uF 50V +80% -20%
C107 PXL439670-1040 0.1uF 50V +80% -20%
C108 PXL439670-1040 0.1uF 50V +80% -20%
C109 PXL456470-3310 330pF 50V 10%
C11 PXL439670-1040 0.1uF 50V +80% -20%
C110 PXL439670-1040 0.1uF 50V +80% -20%
C111 PXL456470-3310 330pF 50V 10%
C112 PYL439630-1060 10uF 10V +80-20%
C113 PXL439670-1040 0.1uF 50V +80% -20%
C114 PXL439670-1040 0.1uF 50V +80% -20%
C115 PXL439670-1040 0.1uF 50V +80% -20%
C116 PXL439670-1040 0.1uF 50V +80% -20%
