Akai DV R3300SS

59
60
VOLTAGE CHART - CONTINUED
VOLTAGE CHART - CONTINUED
U1 (M5703T/SP3721A)
PIN'S NUMBER 1 2 3 4 5 6 7 8
DVD PLAY 3.56 3.56 2.51 2.51 3.50 3.50 3.50 3.50
PIN'S NUMBER 9 10 11 12 13 14 15 16
DVD PLAY 3.52 0 0 2.54 2.54 2.57 3.01 2.53
PIN'S NUMBER 17 18 19 20 21 22 23 24
DVD PLAY 4.29 2.51 0 0 0.17 3.33 0 5.00
PIN'S NUMBER 25 26 27 28 29 30 31 32
DVD PLAY 0 2.51 2.51 5.01 0.12 2.73 2.56 5.01
PIN'S NUMBER 33 34 35 36 37 38 39 40
DVD PLAY 0 4.24 0 3.20 0 3.34 4.95 3.23
PIN'S NUMBER 41 42 43 44 45 46 47 48
DVD PLAY 2.52 2.49 1.83 4.28 3.96 3.33 0 0
PIN'S NUMBER 49 50 51 52 53 54 55 56
DVD PLAY 0 0 2.50 2.52 0 3.47 0.59 2.34
PIN'S NUMBER 57 58 59 60 61 62 63 64
DVD PLAY 2.98 5.01 3.53 3.53 3.80 3.80 3.54 1.41
U5 (M5705)
PIN'S NUMBER 1 2 3 4 5 6 7 8 9 10
DVD PLAY 0 2.50 2.48 5.01 2.49 2.51 3.34 1.26 2.49 3.12
PIN'S NUMBER 11 12 13 14 15 16 17 18 19 20
DVD PLAY 2.56 2.48 2.51 5.01 2.11 0 0.10 2.51 2.51 2.51
PIN'S NUMBER 21 22 23 24 25 26 27 28 29 30
DVD PLAY 2.52 0 2.52 2.49 1.95 5.01 3.21 0 0 0
PIN'S NUMBER 31 32 33 34 35 36 37 38 39 40
DVD PLAY 3.34 0 0 2.62 3.34 0 0 0 3.34 1.65
PIN'S NUMBER 41 42 43 44 45 46 47 48 49 50
DVD PLAY 4.86 0 0 4.86 0 0 2.62 3.33 2.59 3.31
PIN'S NUMBER 51 52 53 54 55 56 57 58 59 60
DVD PLAY 2.60 2.60 0 0 0 2.59 1.66 0 0 0
PIN'S NUMBER 61 62 63 64 65 66 67 68 69 70
DVD PLAY 0 1.59 1.89 1.72 0.22 1.70 2.01 2.01 1.76 2.62
PIN'S NUMBER 71 72 73 74 75 76 77 78 79 80
DVD PLAY 2.59 0 0 0 1.78 3.34 1.82 1.82 2.14 2.10
PIN'S NUMBER 81 82 83 84 85 86 87 88 89 90
DVD PLAY 1.51 1.75 2.00 1.97 1.97 1.98 1.91 0 0.60 2.23
PIN'S NUMBER 91 92 93 94 95 96 97 98 99 100
DVD PLAY 1.63 2.60 3.30 3.09 1.05 1.53 2.60 1.90 0.10 0
PIN'S NUMBER 101 102 103 104 105 106 107 108 109 110
DVD PLAY 4.09 3.99 1.25 0 0 1.71 1.35 0 1.58 0
PIN'S NUMBER 111 112 113 114 115 116 117 118 119 120
DVD PLAY 0.88 1.26 0.75 1.30 3.34 0 1.68 0 0.99 0.66
PIN'S NUMBER 121 122 123 124 125 126 127 128 129 130
DVD PLAY 0 0 0 0 0 1.89 1.90 0 1.81 0
PIN'S NUMBER 131 132 133 134 135 136 137 138 139 140
DVD PLAY 1.81 1.58 0 1.83 0 1.94 1.89 0 0 0
PIN'S NUMBER 141 142 143 144 145 146 147 148 149 150
DVD PLAY 0 0 1.70 0 3.09 3.34 0 0 0.30 0
PIN'S NUMBER 151 152 153 154 155 156 157 158 159 160
DVD PLAY 0 0 0 0 0.25 0.20 0 0 0 0
PIN'S NUMBER 161 162 163 164 165 166 167 168 169 170
DVD PLAY 0 3.34 0.12 0.11 0 2.51 2.51 0 2.68 0
PIN'S NUMBER 171 172 173 174 175 176
DVD PLAY 2.51 2.51 2.51 2.51 2.51 1.75
U3 (BA033FP)
PIN'S NUMBER 1 2 3
DVD PLAY 4.95 0 3.35
U9 (XC61AN1902MR)
PIN'S NUMBER 1 2 3
DVD PLAY 4.88 3.47 0
U2 (BA5983FM)
PIN'S NUMBER 1 2 3 4 5 6 7 8 9 10
DVD PLAY 2.49 2.51 2.51 2.46 2.51 0 2.53 0 3.32 4.88
PIN'S NUMBER 11 12 13 14 15 16 17 18 19 20
DVD PLAY 2.40 2.53 2.51 2.41 2.24 2.08 3.52 0.76 4.88 3.68
PIN'S NUMBER 21 22 23 24 25 26 27 28
DVD PLAY 0 2.84 2.51 2.51 2.48 2.51 2.51 4.90
U29 (BA17805FP)
PIN'S NUMBER 1 2 3
DVD PLAY 11.44 0 5.02
U4 (FAN8082)
PIN'S NUMBER 1 2 3 4 5 6 7 8
DVD PLAY 0 0.37 0.19 1.44 1.44 12.16 12.17 0.37
U27 (LD1117S)
PIN'S NUMBER 1 2 3 4
DVD PLAY 1.85 1.85 3.31 0.59
U28 (LD1117S33C)
PIN'S NUMBER 1 2 3 4
DVD PLAY 0 3.30 4.95 3.30
U6 (M11B416256A-35J)
PIN'S NUMBER 1 2 3 4 5 6 7 8 9 10
DVD PLAY 4.94 1.54 1.54 1.10 1.30 4.95 0.80 0.56 0.65 0.54
PIN'S NUMBER 11 12 13 14 15 16 17 18 19 20
DVD PLAY 0 0 3.33 3.31 0 0.10 0.20 0.11 0.15 4.94
PIN'S NUMBER 21 22 23 24 25 26 27 28 29 30
DVD PLAY 0 0.24 0.25 0.30 0.23 0.33 0.22 3.18 3.21 0
PIN'S NUMBER 31 32 33 34 35 36 37 38 39 40
DVD PLAY 1.97 1.94 1.94 1.95 0 1.83 1.85 0 1.93 0
TUNER SECTION
TEST CONDITION: SET AM/FM ON ONE FREQUENCY
IC401 (TA2099N)
PIN'S NUMBER 1 2 3 4 5 6 7 8
AM 1.97 2.72 0.11 1.97 1.34 6.37 0.48 0
FM 1.95 2 0 2 0.97 7.43 1.29 0
PIN'S NUMBER 9 10 11 12 13 14 15 16
AM 4.96 0.04 5.68 0.76 0.77 0.11 4.89 4.92
FM 4.98 4 4.13 0.77 0.77 0.00 0.52 0.65
PIN'S NUMBER 17 18 19 20 21 22 23 24
AM 1.19 0.48 2.05 1.81 1.97 1.97 6.43 1.97
FM 1.19 1.32 1.99 2.44 1.97 1.97 7.40 1.97
