Akai DV-R4000SS

19
20
ELECTRICAL PARTS LIST - CONTINUED ELECTRICAL PARTS LIST - CONTINUED
Ref. No. Description Mfr's Part No. Qty.
R420 CHIP RESISTOR 12 Kohm +-5% 1/16W (0603/1608) 001-312352-016 1
R467 CHIP RESISTOR 15 ohm +-5% 1/16W (0603/1608) 001-315052-016 1
R426,427 CHIP RESISTOR 1.5 Kohm +-5% 1/16W 001-315252-016 2
R421,442 CHIP RESISTOR 18 Kohm +-5% 1/16W (0603/1608) 001-318352-016 2
R406,416 CHIP RESISTOR 220 ohm +-5% 1/16W (0603/1608) 001-322152-016 2
R405,422,438 CHIP RESISTOR 2.2 Kohm +-5% 1/16W (0603/1608) 001-322252-016 3
R413,417,423 CHIP RESISTOR 22 Kohm +-5% 1/16W (0603/1608) 001-322352-016 3
R418 CHIP RESISTOR 2.7 Kohm +-5% 1/16W (0603/1608) 001-327252-016 1
R411,419,424,425,452 CHIP RESISTOR 3.3 Kohm +-5% 1/16W (0603/1608) 001-333252-016 5
R404,407 CHIP RESISTOR 47 ohm +-5% 1/16W (0603/1608) 001-347052-016 2
R408 CHIP RESISTOR 470 ohm +-5% 1/16W (0603/1608) 001-347152-016 1
R436,447 CHIP RESISTOR 4.7 Kohm +-5% 1/16W (0603/1608) 001-347252-016 2
R446 CHIP RESISTOR 47 Kohm +-5% 1/16W 001-347352-016 1
(0603/1608) (MCR03EZHJ-473)
R414 CHIP RESISTOR 56 ohm +-5% 1/16W (0603/1608) 001-356052-016 1
R437 CHIP RESISTOR 560 ohm +-5% 1/16W (0603/1608) 001-356152-016 1
R428,429,460 CHIP RESISTOR 5.6 Kohm +-5% 1/16W (0603/1608) 001-356252-016 3
R412 CHIP RESISTOR 680 ohm +-5% 1/16W (0603/1608) 001-368152-016 1
R466 CHIP RESISTOR 8.2 Kohm +-5% 1/16W (0603/1608) 001-382252-016 1
CAPACITORS
C511,512 CERAMIC CAP 100 pF/50V +-10% 003-010110-050 2
C421 CHIP CAP 0.001 uF/50V +-10% (0603/1608) 003-510212-050 1
(MCH185C102KK/GRM39X7R102K50PT)
C403,404,409,410,415 CHIP CAP 0.01 uF/50V +-10% (0603/1608) 003-510312-050 5
(GRM39B103K50PT)
C418,427,436 CHIP CAP 0.1 uF/16V +-10% (0603/1608) 003-510412-016 3
(87-A10-260-08G) (C1608JB1C104K) (TDK)
C422,428,429,432,433 CHIP CAP 0.015 pF/50V +-10% (0603/1608) 003-515312-050 5
C438 CHIP CAP 0.0022 uF/50V +-10% (0603/1608) 003-522212-050 1
(UMK107B222KZ-TM)
C402,405,411,414,439,441, CHIP CAP 0.022 uF/50V +-10% (0603/1608) 003-522312-050 8
444,466
C473,476 CHIP CAP 0.0047 uF/50V +-10% (0603/1608) 003-547212-050 2
C406 CHIP CAP 0.047 uF/25V +-10% (0603/1608) 003-547312-025 1
C423 CHIP CAP 0.47 uF/10V +-10% (0603/1608) 003-547412-010 1
(LMK107BL474KA-T)
C424 (F003-556382-016) CHIP CAP 0.056 uF/16V 003-556312-016 1
+-10 (0603/1608)
C420,448,449 (F003-610112-050) CHIP CAP 100 pF/50V 003-610152-050 3
+-5% NPO (0603/1608)
C413 CHIP CAP 15 pF/50V +-5% NPO (0603/1608) 003-615052-050 1
(UMK107CH150JZ-TM)
C446,447 CHIP CAP 24 pF/50V +-5% NPO (0603/1608) 003-624052-050 2
C475 (F003-527012-050) CHIP CAP 27 pF/50V 003-627052-050 1
+-5% NPO (0603/1608) (UMK107CH270JZ-TM)
C523,524 #MYLAR CAP 0.033 uF/100V +-5% 004-033350-100 2
C412 POLY CAP 350 pF/100V +-5% (RADIAL TYPE) 005-035100-100 1
(1A351J/MILOSONIC) (PSR351J/HONJU)
C425 *CdF ELECT CAP 0.47 MFD/50V +-20% (VX/5x11) 006-000400-50C 1
C426 *CdF ELECT CAP 1 MFD/50V +-20% (VX/5x11) 006-001000-50C 1
C467,468,505,506,521,522 ELECT CAP 0.47 MFD/50V +-20% (5x11) 006-000400-50D 6
C417,430,431,517,518,867, ELECT CAP 1 MFD/50V +-20% (5x11) 006-001000-50D 13
868,869,870,871,872,873,
874
Ref. No. Description Mfr's Part No. Qty.
C875,876 ELECT CAP 2.2 MFD/50V +-20% (5x11) 006-002000-50D 2
C513,514,515,516,525 ELECT CAP 4.7 MFD/50V +-20% (5x11) 006-004000-50D 5
C435,645 ELECT CAP 10 MFD/50V +-20% (5x11) 006-010000-50D 2
C437,465,654,655 ELECT CAP 100 MFD/16V +-20% (5x11) 006-010100-16D 4
C419 ELECT CAP 22 MFD/25V +-20% (5x11) 006-022000-25D 1
C416,442,470 ELECT CAP 220 MFD/10V +-20% (6.3x11) 006-022100-10D 3
C471 ELECT CAP 330 MFD/25V +-20% (10x12) 006-033100-25D 1
C408,649 *CdF ELECT CAP 47 MFD/16V +-20% (5x11) 006-047000-16D 2
TC401 TRIMMER CAP CVN610 3-10pF WHITE 007-200610-000 1
(6x6x5mm) (JIN MYOUNG) (CdF)
TRANSISTORS
Q501,502 TRLNPNSST-TAP&TO-092 3DG1815 008-618150-000 2
Q604 TRLPNPPWR-TAP&TO-092 3CA8550 008-685500-000 1
Q605 TR NPNSST-RAD&SC-072 DTC114ES (ROHM) 008-801141-000 1
Q402 CHIP NJFET SST201/SST201B-T1 (SILICONIX) 008-A00201-010 1
TAPE & WHEEL 2SK208Y TOSHIBA
Q409,410 TR PNPPWR-RAD&SC-059 2SA1036K (CHIP) 008-A01036-000 2
Q403,404,405,411 TR NPNSST-RAD&SC-059 2SC2712GR 008-A02712-000 4
(CHIP) (89-327-125-08)
CRYSTAL
CX401 CRYSTAL 7.2 MHz HC-49/U/ALCCCAK 009-607200-000 1
INTEGRATED CIRCUITS
IC606 ICANALOGSWT-4P2T BU4551BF QUAD 2 CHANNEL 010-354551-000 1
ANALOG MULTIPLEXER/DEMULTIPLEXERS
IC506 ICAMP-OP-02CH-DUALV LS4558N 010-404558-003 1
IC401 ICRDS TA2099N (TOSHIBA) (87-A21-173-01) 010-832099-000 1
IC402 ICPLL TC9257F 010-849257-000 1
DIODES
VD401,402 VARI CAP DIODE 2CC149 011-000149-001 2
D401,402,403,404 DIODE IN-4148 ROHM/TELEFUNKEN TAP**50 011-004148-000 4
KEL(NS)(TAP:52mm)/NS(FAIRCHILD)/SEMTECH
INDUCTORS
T408,409 IFT 7PF038C 7.8mm BLACK =012-000022-078 012-000038-078 2
T405 IFT 7M4A1772R 7.5mm YELLOW =012-001720-075 012-001772-075 1
T403 IFT 7M1A1959R 7.5mm RED =012-001905-075 012-001959-075 1
T401 IFT 7M1A1961R 7.5mm BLACK =012-001950-075 012-001961-075 1
L401,403 *CdF INDUCTOR 100 uH /1128/CEC-101K 018-010014-000 2
+-10% LAL03 TB 101K
FILTERS
CF401,402 CERAMIC FILTER SFE10.7MS3-A 019-000107-006 2
CF404 CERAMIC FILTER CDA10.7MG82-A 019-000107-028 1
CF403 (F019-000450-002) CERAMIC FILTER LTU450G2 019-000450-012 1
MISCELLANEOUS
TUNER-FM&&&00STATION FM FRONT END TUNER 042-103010-000 1
PET-3010F/H (EU) (TAE BONG)
JACK COAXIAL JACK HTR-401V 118-030401-000 1
JK401 HEADER MOLEX 2 PINS 5268-02A PITCH 2.5mm 135-005268-020 1
HORIZONTAL TYPE
PIN HEADER 13 PINS S40R20 PITCH:2mm 135-S40R20-130 1
SINGLE ROW RIGHT ANGLE
CENTER SPEAKER SECTION - (SSQCE1)
WIRE
SPK WIRE UL/CSA 2468 2x22AWG (17/0.16mm) 122-002120-407 1
TRANS. w/BK LINE 4M w/TUBE 1xYEL,BLK
