Parts No.
M9-036
037
038a
038b
039a
039b
040
041
042
043
044
045
046
047a
047b
047¢
047d
048
049
050a
050b
Nomenclature
Field Lever, D
Field Lever, E
Start Lever A, with Start
Lever B
Start Button
Prop, Panel
Prop C, Head
Holder B, Spring
Pin B, Spring
Stopper C, Lever G
Hum Bucking Coil
Cycle Change Switch
Micro Switch V-1A
3P Lug Plate
Lever, Belt Change
Stopper, Belt Change Lever
Spring, Belt Change Lever
Spring B, Belt Change Lever
Voltage Adjustment Coil
Shift Lever
Supporting Prop
Nut, Prop
MOTOR BLOCK
051
O5la
051b
O51c
051d
O51le
051f
051g
05ih
051i
051j
051k
0511
051m
052a
052b
053
Motor, Complete
Screw
Stepped Pulley
Motor Pulley
Holder L, Motor
Motor
Motor Fan
Screw, without Head
Prop A, Motor
Prop B, Motor
MP Condenser 2 4'+0.8
250 VAC
Holder, MP Condenser
+Screw Flat Mould 4 x 50
External Shield Plate, Motor
MP Condenser 1, 220 VAC
5P Lug Plate
Drive Belt
FLYWHEEL
054
054a
05 4b
054c
Flywheel, Complete
Capstan
Main Metal Cap, B
Washer Pin
Parts No.
M9-05 4d
05 4e
054f
054g
054i
054j
054k
0541
054m
054n
0540
054p
054q
054r
Nomenclature
Main Metal Case, B
Spring, Main Metal
Nylon Washer
Main Shaft C
4 mm Bail Bearing
Nylon Plate
Plate, Flywheel
Spring Washer
Spring Washer
Nut
Screw
Washer
Prop B, Flywheel
Prop A, Flywheel
SWITCH BLOCK
055a
055b
055c
055d
055e
055f
055g
055h
055i
055j
055k
0551
055m
055n
0550
055p
055q
055r
055s
055t
055u
055v
056a
056b
056c
056d
057a
057b
Knob, Record /Play & Rewind
Fast Forward
Screw
Cam, A-2
Plate, Cam Roller
Cam Roller
Cam, B
Switch Table, A
Spring, E
Lever, I
Screw
4mm Nut
Rotary Switch S-143
Fast/Forward Rewind Shaft
Plate, Cam
Spring, K
Cam, C
+Screw Flat Mould 4 x 6
Switch Table, B-2
Washer
Cam, Amplifier Switch
Washer Pin
Prop, Record Lever
Switch Lever, A
Switch Lever, B
Cam Roller, A
Spring
5P Lug Plate
Resistor
CASE BLOCK
058
058a
059
060
061
062
063
Case, Complete
Case
Rubber Foot
Ventilator
Speaker
Reflector, Speaker
Escutcheon
— 18 —
