5
Features
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
19
20
1. USB Port: Use the included USB cable to connect this USB port to an available
USB port on your computer. This connection allows MPC Element to
send/receive MIDI data to/from the software.
2. MIDI In: Use the included 1/8"-MIDI
adapter and a five-pin MIDI cable to
connect the MIDI Out of an optional
external MIDI device to the MIDI In of
MPC Element.
3. MIDI Out: Use the included 1/8"-MIDI
adapter and a five-pin MIDI cable to
connect the MIDI Out of MPC
Element to the MIDI In of an optional external device.
4. Main: Press this button to view the Main screen in the display and software.
5. Play: Press this button to play the Sequence from the audio pointer's current
position.
6. Play Start: Press this button to play the Sequence from its start point.
7. Stop: Press this button to stop playback.
8. Rec: Press this button to record-arm the Sequence. Press Play or Play Start to
start recording. Recording in this way (rather than using Overdub) erases the
events of the current Sequence. After the Sequence plays through once while
recording, Overdub will be enabled.
IMPORTANT: Do NOT connect
audio devices (e.g., headphones,
monitors, etc.) to the 1/8" MIDI In or
MIDI Out jacks. Use the included
1/8"-MIDI adapters to connect MIDI
devices only.
