Akai MPC Service Manual

1
PT1110685 Button Medium 25 23
1 PT1304315 Power Cable Retainer 1 39
1
PT150430702 LED Master Ring 16 16
1 PT1504309 LED Lens 1 26
1
PT1504311 Lamp Guide(1PCS) 7 27
1 PT1504425 PAD Holder 1 31
1
PT1504426 Fit Washer 2 36
1 PT1510610201 Big buttom(8) 1 18
2
PT15106102 Big button(8) 1
1 PT1510610301 Big button(2) 1 19
2
PT15106103 Big button(2) 1
1 PT1510610401 Knob 1 20
2
PT15106104 Knob 1
1 PT1510643 ALPHA Knob 1 42
1
PT1510693 button(single) 8 25
1 PT1510694 button(3) 4 21
1
PT1510696 button (B) 3 22
1 PT1510698 Button(M) 2 24
1
PT152062403 Side Cap(L) 1 12
2 PT1520624 Side Cap(Left) 1
1
PT152062503 Side Cap(R) 1 11
2 PT1520625 Side Cap(Right) 1
1
PT153012701 Palm Rest(PU Foam) 1 13
2 PT1530127 Palm Rest 1
1
PT153020203 Subchassis 1 4
2 PT1530202 Subchassis 1
1
PU010010010 QUARANTINE CLOTH 2 54
1 RU1504306 Rubber Mat 2 48
1
RU1504341 Rubber Knob 1 14
1 SC0306PW08IBI Screw M3X6 PPWB 4 51
1
SC0306RINI SCREW M3X6 PPN 8 33
1 SC0308ABNI Screw 14 3
1
SC0308PBBI Screw M3X8 PBB Tapping 6 52
1 SC0308PBNI Screw M3X8 PPN Tapping 46 53
1
SC0310RBBI Screw M3X10 PPB Tapping 8 55
1 SC0408PBBI SCREW M4X08 PPB TAPPING 23 30
1
SC2606RINI SCREW M2.6X6 PPN 4 46
1 TSACV0-1 ACV0 DVD Disc 1
1
TWMT15106030101 JOG Knob Assembly 1 29
2 MT151060301 JOG Wheel 1
2
PT1504428 Jog sleeve 1
1 TWPT151063402 Knob Assembly 1
7
2 PT151060702 KNOB CAP(RED)(11) 1
2 PT1510634 Knob Body(Black) 1
1 TWPT151063406 Knob Assembly 2
6
2 PT1510634 Knob Body(Black) 2
2 PT151064501 knob cap(plating) 2
3 PT1510645 Knob Cap 2
1 TWPT151068901 Knob Assembly(Black+Plating) 16
2
2 PT151068701 Knob Cap(plating) 16
3 PT1510687 Knob Cap 16
2 PT1510689 Knob body 16
3 PMRTP199X57372 Holder 0
