Akai MPD18 Service Manual

AD17 Full BOM
Date: 9/26/2008
P/N Description Qty Ref. Des. Approved Mfr. Mfr's P/N PADsMfr.
TOP LEVEL
SHIPPING BOX (KRAFT BOX WITH BLACK SILKSCREEN) 0.5
GIFT BOX (1 COLOR KRAFT BOX) 1
PE BAG 370X280X.03 0.006
LAMINATE PRODUCT BAG 1
7-51-0226 SAFETY INSTRUCTIONS 1
QUICK START MANUAL AD17 (5.5" x 8.5", ~56 pages) 1
PAPER CD HOLDER 1
CD-ROM SOFTWARE USER APPLICATION AD17 1
CA040210002 CORD USB A-B L1000 BLACK + EMI COIL + USB 2.0 TAG
(1 METER)
1
LABEL (SERIAL NUMBER / BARCODE) 1
LABEL (SAFETY) 1
CARDBOARD PACKAGING ENDCAP (Same as AD16) 2
MECHANICALS
PLASTIC TOP PANEL (BLACK PAINT with 2 COLOR
SILKSCREEN)
1
PLASTIC BOTTOM PANEL (BLACK PAINT with NO
SILKSCREEN)
1
AA821460X METAL PAD SENSOR BRACKET (AD16) 1
9-30-0045 SILICON MPC PAD (GREY) 1
AA821466X PLASTIC SLIDER CAP (AD16) 1
PT1510619 PLASTIC SMALL PUSH BUTTONS (AD24) 6
RUBBER FOOT 4
PLASTIC LED STANDOFF 6
SCREWS 12
ELECTRICALS
OTM10030 16-POSITION SENSOR PAD 1

Akai MPD18 Specifications

General

Channels quantity	- channels
Digital sound processing	- bit
DJ mixer	No
USB port	Yes
Product color	Black
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	271.8 mm
Width	205.74 mm
Height	42 mm
