Akai MPD18 Service Manual

AD17 Full BOM
Date: 9/26/2008
P/N Description Qty Ref. Des. Approved Mfr. Mfr's P/N PADsMfr.
0-09-0057 POT 10KB STEREO SLIDE 45mm 1 P26 ALPS MFG CORPORATION
FORWARD ELECTRONICS
CO LTD.
RS45112-0620-C0-P1-B103
RF45112P6120-10K(2B)x2
(YN)
ALPS
0-10-0000 RES 0 OHM 1/8W 5% 1206 1 R27
0-12-0000 RES 0.0 OHM 1/10W 5% 0603 1 R42 Walsin Technology
Corporation
Digi-Key Corporation
Yageo
WR06X000P
311-0.0GRCT-ND
RC0603JR-070RL
0-15-0000 RES 0 OHM 1/10W 5% 0805 1 R9
0-15-0103 RES 10K OHM 1/10W 5% 0805 9 R5 R12
R16-17
R19-20
R23 R25
R28
0-15-0109 RES 1.0 OHM 1/10W 5% 0805 1 R15
0-15-0220 RES 22 OHM 1/10W 5% 0805 2 R35-36
0-15-0221 RES 220 OHM 1/10W 5% 0805 1 R10
0-15-0273 RES 27K OHM 1/10W 5% 0805 4 R6 R18
R21 R26
0-15-0363 RES 36K OHM 1/10W 5% 0805 1 R43
0-15-0471 RES 470 OHM 1/10W 5% 0805 4 R4 R8
R14 R24
0-15-0472 RES 4.7K OHM 1/10W 5% 0805 4 R3 R7
R11 R22
0-15-0473 RES 47K OHM 1/10W 5% 0805 1 R38
0-16-1501 RES 1.50K OHM 1/10W 1% 0805 1 R37
0-17-0221 RES CHIP ARRAY 4 X 220 OHM 1/16W 5% ISOLATED c-
c=0.8mm
2 R1-2 SKYWELL TECHNOLOGY
SEI ELECTRONICS
CTS
VENKEL
PANASONIC INDUSTRIAL
CO
RA03J221-4
RAC16-4D 220 5%
742C083221J
CRN16-4-221JCT
EXBV8V221J
TAD COMPONENTS,
INC.
0-17-8103 RES CHIP ARRAY 8x10K OHM 1/16W 5% COM-BUS c-
c=1.27mm SMD
1 R13 PANASONIC INDUSTRIAL
CO
EXBA10P103J

Akai MPD18 Specifications

General

Channels quantity	- channels
Digital sound processing	- bit
DJ mixer	No
USB port	Yes
Product color	Black
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	271.8 mm
Width	205.74 mm
Height	42 mm
