Akai MPD18 Service Manual

AD17 Full BOM
Date: 9/26/2008
P/N Description Qty Ref. Des. Approved Mfr. Mfr's P/N PADsMfr.
1-55-0561 CAP 560pF NPO 0805 5% 50V 4 C5 C14
C18 C20
1-61-0180 CAP 18pF NPO 0603 5% 50V 2 C1-2 Digi-Key Corporation
Digi-Key Corporation
TDK Corporation
Walsin Technology
Corporation
445-1272-1-ND
445-1272-2-ND
C1608C0G1H180J
0603N180J500L
1-62-0103 CAP 0.01uF X7R 0603 10% 50V 6 C3 C7 C9
C11-12
C15
Digi-Key Corporation
Walsin Technology
Corporation
Pan Overseas Electronic Co.,
LTD.
Pan Overseas Electronic Co.,
LTD.
Walsin Technology
Corporation
KEMET Electronics
Corporation
399-1091-1-ND
0603B103K500CT
A0603R103KCT
U0603R103KCT
0603B103K101CT
C0603C103K5RACTU
1-62-0104 CAP 0.1uF X7R 0603 10% 50V 11 C4 C8
C10 C13
C16 C19
C21-22
C24 C27
C95
Digi-Key Corporation
KEMET Electronics
Corporation
Walsin Technology
Corporation
399-5089-1-ND
C0603C104K5RACTU
0603B104K500C
1-70-1471 CAP 4.7uF TANT-A SMD 20% 6.3V 1 C6 NICHICON (AMERICA)
CORP.
VENKEL
AVX
PANASONIC INDUSTRIAL
CO
F930J475MAA(RoHS)
TA006TCM475MAR
TAJA475M010R
ECSTOJY475R
1-70-2102 CAP 10uF TANT-A 20% 10V 1 C23 PANASONIC INDUSTRIAL
CO
ECST1AY106R

Akai MPD18 Specifications

General

Channels quantity	- channels
Digital sound processing	- bit
DJ mixer	No
USB port	Yes
Product color	Black
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	271.8 mm
Width	205.74 mm
Height	42 mm
