Akai MPD18 Service Manual

AD17 Full BOM
Date: 9/26/2008
P/N Description Qty Ref. Des. Approved Mfr. Mfr's P/N PADsMfr.
2-49-0070 DIODE SWITCHING DUAL COMMON-CATHODE SOT-23 8 D1-8 Infineon Technologies
ROHM
NXP Semiconductors
FAIRCHILD SEMI
ON SEMICONDUCTOR
BAV 80 B5003(RoHS)
BAV70T116(RoHS)
BAV70 T/R(RoHS)
BAV70(RoHS)
BAV70LT3G(RoHS)
2-51-4401 TRANS NPN 2N4401 40V 1A SOT-23 2 Q2-3 FAIRCHILD SEMI
Micro Commercial
Components
ON SEMICONDUCTOR
DIODES INC.
MMBT4401
MMBT4401-TP(RoHS)
MMBT4401LT1G(RoHS)
MMBT4401-7-F(RoHS)
2-61-7223 REG VOLTAGE NJU7223DL1-33 3.3V TO-252 1 U4 JRC (NEW JAPAN RADIO
COMPANY)
NJU7223DL1-33 JRC
2-71-1324 IC LMV324 QUAD OP AMP LOW VOLTAGE RAIL-TO-RAIL
OUTPUT SOP-14
1 U1 NATIONAL
SEMICONDUCTOR
NATIONAL
SEMICONDUCTOR
LMV324M/NOPB(RoHS)
LMV324M
NATIONAL
3-01-0001 LED YELLOW ROUND T1(3mm) 6 LED1-6 EVERLIGHT ELECTRONICS
CO. LTD.
EL204YD
4-08-0401 CON USB 4-PIN FEMALE PC-MOUNT 90° W/SHIELD 1 J7 WIESON ELECTRONIC CO.
AMP INC.
3700-4CBT1T1W
787780-1
WIESON
4-14-1120 HEADER DIL 20-PIN 0.1 SHRD 1 J3 JAWS ELECTRONIC LTD. 3500-GS-20
4-15-2005 CON SIL 20-PIN 1mm FFC/FPC 90° ZIF BOTTOM-CONTACT 1 J1 J.S.T. MFG CO. LTD 20FMZ-ST(LF)(SN) JST
6-02-0065 SWITCH TACT SPST 5mm PITCH 4.3mm HEIGHT 160gf 6 SW1-6 FORWARD ELECTRONICS
CO LTD.
SFKHVBB3425-YN(RoHS) Forward Electronics
7-01-0058 CRYSTAL 8 MHz PARALLEL 18pF SMD HC-49/UP 1 X1 YOKETANT CORP
ECLIPTEK INC
R49SSB-008000-FA-18-30-YA
EC1SM-8.000M-TR
ECLIPTEK
CORPORATION
NEW PART IC MPU STM32F103R8T6 32-BIT 64K FLASH 72MHZ 3.3V
TQFP-64
1 U2 ST Microelectronics STM32F103R8T6 ST
MICROELECTRONICS
PCB Bare PCB, 2-Layer, 200mm x 60mm (apx 50% of AD32 right
PCB)
1

Akai MPD18 Specifications

General

Channels quantity	- channels
Digital sound processing	- bit
DJ mixer	No
USB port	Yes
Product color	Black
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	271.8 mm
Width	205.74 mm
Height	42 mm
