Akai MPD226 Quick Start Guide

The current fader, knob and button assignments are as follows:
MD226
Logic Pro X
Faders (Bank A, B and C)
Track Volume 1-12
Knobs (Bank A, B and C)
Track Pan 1-12
Buttons (Bank A, B and C
Track Mute 1-12
Enable the MPD226 Transport and sync with Logic Pro X
1. In Logic, select File > Project Settings > Synchronization.
2. Click on the MIDI tab
3. Next to Transmit MIDI Clock, check off the box for Destination 1 and in the drop-down menu,
select MPD226 Port A.
4. Under MIDI Machine Control (MMC), check off the box for Listen to MMC Input.
The Logic X preset on the MPD226 should already be set to the proper settings and you should see the
transport (Play/Stop/Record) start working immediately. If not, check your Clock Source Setting and
Transport Type on the MPD226:
1. Press GLOBAL on the MPD226.
2. Use the right arrow to find the Clock Source page.
3. Set this to External.
4. Press the EDIT button.
5. Press the PLAY button to edit the Transport.
6. Set the Type to MMC/MIDI.
Further Technical Support
Whether you are a customer or dealer, if you already own an Akai Pro product, or if you just have pre-
sales questions, the Akai Pro technical support team is available to help!
Visit the link below to connect with any of the following support options: online community support,
phone support, email support.
 www.akaipro.com/support

Akai MPD226 Specifications

General

Current	1 A
Input voltage	6 V
Power supply type	AC
Product color	Black
Number of controls	36
Drum pads backlight	Yes
Number of drum pads	16
Number of mixer channels	4 channels
USB version	2.0
USB connector type	USB Type-B
USB ports quantity	1
Minimum RAM	1 GB
Minimum processor speed	1.25 GHz

Weight and Dimensions

Depth	254 mm
Width	333 mm
Height	48 mm
Weight	1300 g
