Page #10 background imageLoading...
Page #10 background image
1 PT153003301 Top Panel Paint/Print 1
3
2 PT1530033 Top Panel 1
1 RU150435601 Rubber 1
16
1 RU1530602 RUBBER FOOT 4
15
1 SC0208RBCI SCREW M2X8 PPC TAPPING 4
25
1 SC0306RBNI Screw M3X6 PRN Tapping 3
11
1 SC0308RBNI Screw M3X8 PRN Tapping 30
5
1 SC0310BIBI SCREW M3X10 PBB 1
20
1 SC0310RBBI Screw M3X10 PPB Tapping 12
2
1 SC0408PBBI SCREW M4X08 PPB TAPPING 26
14
1 TW61701AYAH0102 Key Board Assembly 1
10
2 BAGL-55A CABLE CLIP 55L 1
2 CN0225408501 Flat Cable 2Pin Pitch 2.54mm Single Row 1
Length 850mm Pin/Female Header
2 CN1625402501 Flat Cable type 8p*2 pitch2.54mm Row 1
Length 250mm Female/Female Header
2 CN1625403901 Flat Cable Type 8P*2 Pitch 2.54mm Dual 1
Row Length 390mm Female/Female Header
2 KB61701AYAH01 61 Key board weighted with aftertouch 1
1 TWPC13A00903 Main PCB Assembly 1 29
2 AA822748X Diode BAV99 6 D2,3,7,9,11,200
2 AL0-17-0101 RES Array 4X100 1/10W 0603 11 R36,49,89,103,104,124~127,130,131
2 AL0-17-0103 RES Array 4X10K 1/10W 0603 1 R111
2 AL1-70-1471 Solid Tantalum Electrolytic 1 C50
Capacitors4.7uF/10V 20% A-SMD
2 AL2-50-4149 Diode Single 1N4148 100V 200mA SOT-23 1 D8
2 AL2-51-0140 Schottky Barrier Rectifiers Diode 2 D6,10
B140-13-F SMA
2 AL2-51-4401 Transistor 2N4401 NPN SOT-23 (Transistor 4 Q1,2,8,9
MMBT4401LT1 NPN SOT-23)
2 AL2-51-4403 Transistor 2N4403 PNP SOT-23 4 Q4,5,7,11
2 AL2-52-5242 Diode MMBZ5242B 1 D5
2 AL2-54-6306 Mosfet FDC6306P P-CH SSOT-6 1 U3
2 AL2-61-7223 IC NJU7223DL1-33 3.3V TO-252 1 U1
2 AL2-71-1324 IC LMV324 SOP-14 1 U8
2 AL2-73-4051 IC74HC4051 Single 8-Chan Mux 16P Soic 1 U4
2 AL4-00-0002 MIDI Jack 8P 90° Female 2 J4,5
2 AL4-02-0007 Jack 1/4 Stereo 7-Pin Fem Mini W/Grnd 3 J1,2,3
Lug Straight
2 AL4-08-0402 Con USB 4-Pin Female PC-MNT Horizontal 1 J6
2 AL4-14-0116 CONNECTOR 6P DIL 2 J10,11
2 AL4-15-0004 Connector 4P 2.54 180° 1 J12
2 AL6-02-0059 Switch push 2P2T Dual Row Lock 1 SW1
2 CS102J5003NPO CCAP SMD 1nF/50V 5% 0603 NPO 13 C12,14~16,43,61,62,64~69
2 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 2 C47,51
2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 47 C1,4~6,9~11,13,17~20,22~24,28,30~33
C36~40,42,45,46,48,52,54~60,63,70~74
C163,171,200,201
2
CS105K1605X7R CCAP SMD 1uF/16V 10% 0805 X7R 4 C21,78,177,178
2
CS106K1606X7R CCAP SMD 10uF/16V 10% 1206 X7R 2 C53,176
2
CS180J5003NPO CCAP SMD 18pF/50V 5% 0603 NPO 2 C29,49
2
DIBAW56 Switch Diode BAW56 SOT-23 2 D4,13
2
DIPHLTV-356T-B Opticak Encode Senser Diode LTV-356T-B 1 U2
2
ECS10710D Capacitor Electrolytic 100UF 10V SMD-D 3 C3,165,181
2
ECS47525B Ecap 4.7uF/25V 4*5.4mm SMD 1 C2
2
FCN2S1002601 FCN Dual Touch 180° Pitch=1.0mm 26P 1 J14
