Akai MPK61 User Manual

2 RS056K10F03 RES 56K 1% SMD 0603 1 R26
2 RS080608F05 RES 806 1% SMD 0805 1 R74
2 RS100K10F03 RES 100K 1% SMD 0603 2 R37,40
2 RS11K808F05 RES 11.8K 1% SMD 0805 1 R63
2 RS15K808F05 RES 15.8K 1% SMD 0805 4 R60,61,75,83
2 RS1K3308F05 RES 1.33K 1% SMD 0805 1 R53
2 RS22K108F05 RES 22.1K 1% SMD 0805 1 R64
2 RS2K3208F05 RES 2.32K 1% SMD 0805 1 R56
2 RS33K208F05 RES 33.2K 1% SMD 0805 2 R41,58
2 RS3K3208F05 RES 3.32K 1% SMD 0805 4 R76,77,95,96
2 RS47K508F05 RES 47.5K 1% SMD 0805 3 R59,81,84
2 RS4K7508F05 RES 4.75K 1% SMD 0805 2 R54,55
2 RS820K10F03 RES 820K 1% SMD 0603 1 R31
2 RS82K508F05 RES 82.5K 1% SMD 0805 1 R78
2 TE512540801 TERMINAL 8P 2.54mm 1 J15
2 TE622000401 Pin Header 90° Pitch:2.00mm S 1 J13
2 TE962542001 TERMINAL 20P 2.54MM 1 J8
2 UHLPF3218MF100M 10UH 1A 0.29 SMD 2 L1,2
2 XTM08000X6F1 CRYSTAL 8MHZ HC49SMD 1 X1
1 AL9-79-050801 TOP LEFT PCB ASS'Y 1
2 AA822748X DIODE BAV99 9 D7,10~17
2 AL2-49-0070 DIODE BAV70 8 D1~6,8,9
2 AL2-51-4401 TRANS NPN 2N4401 40V 1A SOT-23 2 Q1,2
2 AL2-62-0004 IC 74AHC04 1 U3
2 AL2-71-1324 IC LMV324 SOP-14 1 U1
2 AL3-02-0080 LED AMBER L-169XSYDK 3 LED1~3
2 AL9-40-0508 FRONT LEFT PCB 2 Layer FR-4 1. 1 -
2 BALE48201-5A LED FIXED 1.5MM 3 (LED1~3)
2 CN0420004502 FLAT CABLE MULTI COLORED 4PIN 1 J3
2 CN0620002301 Flat Cable Multicolored 6P Pit 1 J1
2 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X 4 C5,7,8,10
2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7 8 C1~3,6,13~16
2 CS561J5005NPO CCAP SMD 560pF/50V 5% 0805 NPO 4 C4,9,11,12
2 FCN2R1002001 FCN DUAL TOUCH 90° PITCH:1.0M 1 J4
2 FCN2R1002601 FCN DUAL TOUCH 90° PITCH=1.0M 1 J5
2 IC74LVC139AD IC74LVC139AD SOP-16 1 U2
2 LD1030 LED GREEN 3 LED4~6
2 PT111048009 FIXED BASE,LED 9MM 3 (LED4~6)
2 RS000008J05 RES 0 5% SMD 0805 1 R28
2 RS001508F05 RES 15 1% SMD 0805 2 R2,3
2 RS001K08F05 RES 1K 1% SMD 0805 1 R1
2 RS006808F05 RES 68 1% SMD 0805 3 R13,15,16
2 RS010K08F05 RES 10K 1% SMD 0805 6 R5,8,10,14,18,22
2 RS022008F05 RES 220 1% SMD 0805 3 R25~27
2 RS027K08F05 RES 27K 1% SMD 0805 4 R11,12,17,20
2 RS047008F05 RES 470 1% SMD 0805 4 R4,9,19,21
2 RS04K708F05 RES 4.7K 1% SMD 0805 4 R6,7,23,24
2 SWSKHVBB3420 SWITCH 4.3 10 S1~10
2 TE10200602 Pin Header 90° Pitch:2.00mm S 1 J2
1 TWPC09A00501 TOP RIGHT PCB ASS'Y 1
2 AL9-79-045201 RIGHT FRONT PCB ASSEMBLY 1

Akai MPK61 Specifications

General

Type	MIDI Keyboard Controller
Keys	61
Velocity Sensitivity	Yes
Aftertouch	Yes
Transport Controls	Yes
Arpeggiator	Yes
USB	Yes
Pads	16
Knobs	8 assignable
Faders	8 assignable
MIDI I/O	In/Out
Pedal Inputs	1 Sustain, 1 Expression
Power Supply	USB or optional AC adapter
Software Included	Ableton Live Lite
