Bill of Materials (BOM): Rear-Right PCB
P/N Description Qty Ref. Des.
0-13-1000 RES 100 OHM 1/10W 1% 0603 SMD 4 R1-2 R5 R7
0-13-1002 RES 10.0K OHM 1/16W 1% 0603 5 R8-10 R14-15
0-13-1501 RES 1.50K OHM 1/10W 1% 0603 5 R13 R18-21
0-13-3321 RES 3.32K OHM 1/10W 1% 0603 2 R11 R16
0-13-4752 RES 47.5K OHM 1/10W 1% 0603 3 R17 R22-23
0-15-0102 RES 1K OHM 1/10W 5% 0805 3 R3-4 R6
1-07-1476 CAP 47uF ELEC 20% 6.3V 1.5x4x7mm 3 C5-6 C8
1-55-0101 CAP 100pF NPO 0805 5% 50V 4 C1-4
1-61-0681 CAP 680pF NPO 0603 5% 50V 2 C13-14
1-62-0104 CAP 0.1uF X7R 0603 10% 50V 5 C9-12 C15
2-50-4149 DIODE SIGNAL 1N4148 100V 200mA SOT-23 3 D1-3
2-51-4401 TRANS NPN 2N4401 40V 1A SOT-23 2 Q3 Q7
2-51-4403 TRANS PNP 2N4403 40V 800mA SOT-23 3 Q5-6 Q8
2-54-2114 TRANS SMALL-SIGNAL NPN 2SD2114K/BBV SC59 3 Q1-2 Q4
2-71-4581 IC NJM4580M DUAL OP-AMP DMP-8 2 U1-2
4-02-0007 JACK 1/4 STEREO 7-PIN FEM MINI W/GRND LUG STRAIGHT 2 J1-2
4-15-0210 HEADER SIL 10-PIN 2mm MALE 90° SHRD 1 J3
DNS_0-13-
1005
DO NOT STUFF RES 10.0M OHM 1/10W 1% 0603 1 R12
DNS_1-61-
0681
DO NOT STUFF CAP 680pF NPO 0603 5% 50V 1 C7
