Åkerströms SESAM 800 K3 User Manual

Description of the system 8 (16)
Sesam 800 K3 RXDIN USA Manual Document-ID: 946415-000
Version: A0 Author: SH
4 Description of the system
4.1 Receiver
This document covers receiver model Sesam 800 RX DIN
• 3 Single Pole Double Throw relays.
• Memory capacity: up to 100 transmitters.
• Designed for DIN rail
4.2 Transmitter
This document covers transmitter model Sesam 800 Keyring K3:
• Miniature 3 button transmitter.
• Suitable for controlling 3 non-response time critical func tions.
5 Description of Sesam 800 RX DIN receiver
Figure1. Sesam800RXDINmodelconnectionsandbuttons
1.Learn/Erasebutton
2.Powerconnection,
3. Connection to relay 1
4. Connection to relay 2
5. Connection to relay 3
6.LED5Squelch
LED6Status
LED7Learn
