8. Take the left earcup
down.
9. . Take the right earcup
down.
7. Remove the screws from the
left /right earcup by electric
screw driver, 12pcs in total.
11. Take out the Main PCBA
Board by electric screw driver.
Need clear
the glue
firstly.
Need clear
the glue
firstly
10. Take out the ANC PCBA
Board by electric screw driver.
ᤄᶮFPCᧂ
㓯ᢓ
Loosen the
FPC button.
12. Main PCBA Board.
