20. Remove the screw which fix
logo badge and volume ring by
electric screw driver.
᣶⭥
⊐㓯
Remove
screws
21. Separate the left/right earcup.
Logo
Badge
Volume
Ring
Left
Earcup
Right
Earcup
Bolt
Stop part
