Level 1.- TIMING CONFIGURATION
Level 1.- CONFIGURATION OF PROTECTIONS AND ALARMS
Level 1.- DATE AND TIME CONFIGURATION
Description
Units
Min
Def
Max.
t01
Minimum operation time for a compressor
sec. x10
1
2
999
t02
Minimum disconnection time for a compressor **
sec. x10
1
2
999
t03
Delay time between the compressor start-up/stage and the next one
sec.
1
30
999
t04
Delay time between the compressor stop/stage and the next one
sec.
1
10
999
t05
Minimum operation time for a fan
sec. x10
1
1
999
t06
Minimum disconnection time for a fan
sec. x10
1
1
999
t07
Delay time between the fan start-up and the next one
sec.
1
2
999
t08
Delay time between the fan stop and the next one
sec.
1
2
999
EP
Output to level 1
Description
Units
Min
Def
Max.
A01
Number of active compressor stages with error in probe 1
0
0
***
A02
Number of active fans or inverter % with error in probe 2
Without inverter
0
C05
C05
With inverter
0
100%
100%
A03
Low pressure alarm in probe 1
bar
-0.7
0
75
A04
Low pressure alarm differential
bar
0.1
1.0
20
A05
High pressure alarm in probe 2
bar
-0.7
20
75
A06
High pressure alarm differential
bar
0.1
1.0
20
A07
Alarm delay after reaching the value
seg.
0
60
999
A08
Delay of temperature alarms in the start-up.
seg.
0
0
255
A09
High pressure alarm limit (per digital input) per hour without manual reset.
(If I07 or I08=1) (0=deactivated) Once the limit has been exceeded a manual reset will
be required for each new alarm.
0
0
255
EP
Output to level 1
Description
Units
Min
Def
Max.
r01
Hour
00
00
23
r02
Minutes
00
00
59
r03
Day
1
1
31
r04
Month
1
1
12
r05
Year
00
15
99
EP
Output to level 1
Level 2Level 2Level 2
** If the compressor is equipped with an inverter, this period of time halves.
*** The number of stages depends on the configuration selected in the wizard.
