Akron Brass AkroFlow 9301 - Product Warnings

STYLE 9301 AkroFlow™ ™ FLOW METER
INSTALLATION, OPERATING, AND MAINTENANCE INSTRUCTIONS
PHONE: 800.228.1161 I WEBSITE: www.akronbrass.com
Sheet: 127710
Revision: 9/2020
Page:2 of 8
Read and follow the operating instructions before use.
For firefighting use only.
Product Ratings
Specifications:
Type
Electromagnetic (Mag-Meter)
Weight
5.3# (2.4kg)
Dimensions: L x W x H
10-3/4” (273mm) x 4-3/8” (111mm) x 6” (152mm)
Flow Passage
2” (50.8mm) Full Port
Fittings
2-1/2” female fulltime swivel inlet, 2-1/2 male thread outlet
Thread choices
NH, BSP, NPSH
Maximum operating pressure
200psi (13.8 bar/ 1380 kpa)
Operating temperature range
10° to 130°F (-12° to 54°C)
Accuracy
±1%
Flow range
10gpm to 600gpm (38lpm to 2270lpm)
Pressure drop across the meter
4psi @ 600gpm (0.28 bar @ 2270lpm)
Materials
Body
Glass-filled polypropylene
Inlet
Hardcoat aluminum
Outlet
Hardcoat aluminum
Electrodes
316 stainless steel
Display Cover
Polyethylene
Flange Clamps
300 series stainless steel
Display
Flow Rate with totalizer
Digits
6
Units
Gallons/Minute or Liters/Minute (Selectable)
Power
Batteries not
supplied with
Export units
6 AA Lithium cells, replaceable. Life; 1 year with meter in use; 3
years dry. Low battery indicator “Lo Batt”.
Empty Pipe Detection
Hardware/software, conductivity-based
NEMA rating
NEMA 4X standard: -40° to 176°F (-40° to 80°C) storage
IP Rating
IP64
Product Warnings
•
Indicates a hazardous situation which, if not avoided, WILL result in death or
serious injury.
•
Indicates a hazardous situation which, if not avoided, COULD result in death or
serious injury.
• Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury.
• Addresses practices not related to personal injury.
