en
Original instructions for use
12 477 219_b
ORIGINAL INSTRUCTIONS FOR USE
Contents
About this handbook........................................ 12
Product description.......................................... 12
Safety instructions............................................13
Startup..............................................................14
Maintenance and care..................................... 15
Disposal............................................................16
Troubleshooting................................................16
EC declaration of conformity............................17
Warranty...........................................................18
ABOUT THIS HANDBOOK
Read this documentation before starting up
the machine. This is a precondition for safe
working and flawless operation.
Observe the safety warnings in this docu-
mentation and on the product.
This documentation is a permanent integral
part of the product described and must be
passed on to the new owner if the product is
sold.
Explanation of symbols
CAUTION!
Following these safety warnings care-
fully can prevent personal injury and/or
material damage.
ADVICE
Special instructions for greater ease of
understanding and improved handling.
PRODUCT DESCRIPTION
Product overview
1 pump housing
2 filler screw
3 pump outlet/pressure hose connection
4 motor housing
5 valve
6 reservoir
7 pressure gauge
8 connection cable
9 draining screw (pump chamber)
10 pressure switch pump
11 compensation hose
12 draining screw (filter chamber)
13 pump inlet/suction hose connection
14 transparent filter cover
15 angular nipple
16 flat seal
17 connection nipple
18 round seal ring
19 pressure hose (accessory)
20 AL-KO suction fitting (accessory)
21 seals for filter
22 filter
23 non-return valve
24 seal
25 round seal ring (transparent cover filter
chamber)
26 flat seal
Designated use
The domestic water system is designed for home
use in your house or garden. Please observe the
technical data given in the instructions before put-
ting the system into operation.
Your domestic water system has been designed
for use in the following applications:
irrigation and watering, e.g. of your lawn or
flower and vegetable gardens
domestic water supply
increasing pressure in the domestic water
supply. Please observe the regulations is-
sued by your local water works. If necessary,
ask a plumber.
The system is designed to pump only the following
liquids:
clear water
rain water
