TECHNICAL SPECIFICATIONS
General:
Operation frequency: 2400 - 2483,5 ISM
Useable range: 30 - 100 Meter
Video
Input Impedance: 75 Ohm
Interface level: 1 Vp-p
Frequency response: 0 - 5,0 MHz
Audio
Input Impedance: 600 Ohm
Interface level: 600 mVp-p
Frequency response: 300 - 3400 Hz
Operation temperature: 5 - 50 °C
Camera:
Microwave output power: +5 ~ +10 dBm
Modulation: FM
Maximum frequency deviation: 20 MHz
Audio Sub, carrier frequency: 6,0 MHz, 6,5 MHz
Auto Trigger level: 50 dBa - 60 dBa
Infrared detection range: 3 - 5 Meter
Operation Current: 100 mA DC MAX
Power supply: 12 V DC/400mA (Adapter)
Monitor:
Receiver sensitivity: -80 ~ -85 dBm
Monitor mode: B/W
Mon. bright desc. gradation: >6
Mon. center horizontal resolution: 350 lines
Operation current: 700 mA DC
Power supply: 15 V DC/800mA (Adapter)
10 pcs size “C” (Battery)
19
