High-Capacity Reel SER 7342
Alemite LLC 3 Revision (10-13)
Item
No.
Part No. Description Qty Notes
Numeric Order
Part # (Item #)
1 Nut, Flange 5/16 " -18 16
14534 (9)
2 Sheave Assembly 1
50876 (8)
3 339464 Shaft and Flange Assembly 1
171000-5 (21)
4 339521 Key, Square 1 171007-32 (37)
5 Screw, 5/16 " -18 x 3/4 " 20 171007-33 (15)
6 339476 Shaft and Riser Assembly 1
171009-13 (39)
7 320353 Bushing, 1 " NPTF (m) x 3/4 " NPTF (f) 1 Use w/ 3/4 " hose 320353 (7)
8 Nut, Wing, 1/4 " -20 2 339197 (25)
9 Washer, 5/16 " 2
339208 (28)
10
339219-1 U-Bolt, 1-1/8 " 1 Use w/ 3/4 " hose 339209 (34)
339219-2 U-Bolt, 1-1/2 " 1 Use w/ 1 " hose 339210 (23)
339219-3 U-Bolt, 1-1/4 " 1 Use w/ 1 " hose 339219-1 (10)
11 339469-2 Spring Assembly, Power 1 Includes Gasket 339219-2 (10)
12 Nut, Flange 3/8 " -16 11
4 in kit, 1 in kit
339219-3 (10)
13 Arm, Short 1
339435 (32)
14 339455 Plug, Button 1
339439 (24)
15 171007-33 Ring, Retaining 4
1 in
kit
339441 (22)
16 Plate, Hose Guide 1
339443 (2)
17 Post and Shaft Assembly, Long 2
339446 (13)
18 Post and Shaft Assembly, Short 2
339447 (33)
19 Roller Assembly, Long 2
Includes Item 21
339448 (16)
20 Roller Assembly, Short 2
339451-1 (20)
21 O-Ring, 1/4 " ID x 3/8 " OD 8
339451-2 (19)
22 Post, Spring 1
339455 (14)
23 339210 Spring, Extension 1
339456 (27)
24 Pawl and Shaft Assembly 1
339457 (26)
25 339197 Arbor, Spring 1
339460 (31)
26 339457 Housing, Bearing 2 Includes Two Halves
339461 (5)
27 339456 Bearing 2
339462 (12)
28 Washer, 0.445 " ID x 0.75" OD 8
339463 (29)
29 Bolt, Ribbed-Neck, 3/8 " -16 x 3/4 " 2 339464 (3)
30 Bolt, Ribbed-Neck, 3/8 " -16 x 1-1/4 " 2 339467 (36)
31 Screw, 1/2 " -13 x 3/4 " 1
339469-2 (11)
32 Base Assembly 1 339476 (6)
33 Arm, Long 1 w/o Decal 339481 (38)
34 339209 Washer 1 339483 (35)
35 339483 Washer, Wave 1
339484 (30)
36 339467 Ratchet 1
339516-1 (18)
37 171007-32 Ring, Retaining 1
339516-2 (17)
38 339481 Body, Swivel 1
339520 (40)
39 O-Ring, 1-3/16 " ID x 1-5/16 " OD 2 339521 (4)
40 T-Seal 2
387370 (1)
Legend:
Part numbers left blank (or in italics) are not available separately
designates a repair kit item
Repair Kits
Part No. Kit Symbol Description
393727 Kit, Hose Guide
393724 Kit, Pawl and Shaft Assembly
393725 Kit, Swivel Repair
