Available Controls and Components

FRONT

1. Volume Up and Down

2. Message (Play)back

3. (Forward) to next message

4. (Wakeup) the unit from sleep

5. (Erase) the selected message

6. (Record) the current message

7. (Mic) is the microphone location

8. (Freq and Code Select)

9. (Options Selections)

10. Speaker

11. Call Button

12. Shield Mount

BACK

1. Mounting Bracket

2. Mounting Bracket Lock Screw

3. Auxillery Call Button or Power Jack

EasyAssist Controls
