8
WIRING HARNESSES
Keep all wiring away from moving engine parts, exhaust pipes and high-
tension cable. Tape wires that pass through holes on the firewall to prevent
fraying. Watch out for sharp edges that may damage wires and cause
short circuits.
CAUTION: Do not connect the wire harness to the control
module until all wiring to vehicle is complete.
1.Dual pulse door unlock output
2.Factory disarm signal output
3.Start Status (shock sensor by-pass control) Output
VIOLET
To Next Page
