TECHNICAL SPECIFICATIONS
POWER SUPPLY: 18V AC, 700mA
INPUT CHANNELS: MIC INPUT Sensitivity Range: -69dBu to -19dBu nominal, +18dBu maximum
LINE INPUT Sensitivity Range: -49dBu to -+1dBu nominal, +18dBu maximum
MIC INPUT / LINE INPUT Gain Range: -∞ to +20dB
EQUALIZATION: HI: 12kHz, ±15dB
MID: 120Hz – 4KHz, or 1Khz, ±15dB
LO: 80Hz, ±15dB
AUX SENDS: AUX SEND Gain Range: -∞ to +10dB
AUX RETURNS: AUX RETURN A Gain Range: -∞ to +10dB
Effects Level / AUX RETURN B Gain Range: -∞ to +10dB
CHANNEL LEVELS: Channel Level Gain Range: -∞ to +10dB
MASTER LEVELS: Main Mix / Monitor Mix Gain Range: -∞ to +10dB
1/4" INPUTS: AUX RETURN Level: -16dBu nominal, +18dBu maximum
RCA INPUTS: 2 TRACK IN Level: -10dBV nominal, +18dBV maximum
1/4" OUTPUTS: MAIN OUT / MONITOR OUT / AUX SEND: +4dBu nominal, +18dBu maximum
RCA OUTPUTS: 2 TRACK OUT Level: -9dBV nominal, +19dBV maximum
USB AUDIO INTERFACE: Sampling Rate: 44.1/48 kHz
Resolution: 16-bit
Interface: USB 1.1 or better
* Specifications are subject to change without notice.
