ALFRA APS 70 - Delivery; Technical Data

22
Delivery
The following standard components are included with the ALFRA APS punching unit:
• an APS punching unit
• a 5 m long hydraulic hose
• a tool set of punches and die-plates:
Hole-Ø 18 mm with APS 70
Hole-Ø 22 mm with APS 120
• a hanging bracket (with APS 70 and APS 120)
• a depth stop
Technical Data
Single-acting hydraulic punching unit with automatic return by means of a neoprene spring:
Type description:
ALFRA-Press APS 70
ALFRA-Press APS 120
Product No.:
23002
23004
Maximum Hole Ø:
22 mm
25 mm
Maximum Long
Hole:
22 x 14 mm
25 x 18 mm
Maximum material
thickness with steel
S275
13 mm
16 mm
Total punching time
with pumps:
SC 05 II B
10 sec.
16 sec.
SC 17
4 sec.
5 sec.
Hole depth:
70 mm
110 mm
Maximum pressure:
700 bar
700 bar
Punching force:
30 t
44 t
Punch deviation:
18 mm
25 mm
Weight:
21 kg
47,3 kg
Shipment:
 Punching nut
 Control cable
 Hydraulic hose 5 m
 Clamping nut
 1 each punch and
die Ø 18 mm
 Depth stop
 Hanging bracket
 Punching unit
 Control cable
 Hydraulic hose 5 m
 Clamping nut
 1 each punch and
die Ø 22 mm
 Depth stop
 Hanging bracket
