DMX PROTOCOL 31 CHANNELS
CH
Main description
Value
Functions
1
LED Rotating plate
motor
0-127
0-360° position selection
128-191
Clockwise rotating infinitely from
fast to slow
192-255
Anti-clockwise rotating infinitely
from slow to fast
2 LASER rotating motor
0-127
0-360° position selection
128-191
Clockwise rotating infinitely from
fast to slow
192-255
Anti-clockwise rotating infinitely
from slow to fast
3
Motor Speed
0-255
From fast to slow (1CH and 2CH
values are valid from 0-127)
4
Green Laser
0-15
Light off
16-249
Strobe from slow to fast
250-255
Light on
5
LED Strobe
0-15
Light off
16-255
Strobe from slow to fast
6
Total Dimming
0-255
0-100%
7
Strobe
0-15
Light on
16-255 from slow to fast
8
Auto effect
0-15
Invalid
16-240 Auto
241-255
Sound
9
Auto speed
0-255
Speed from slow to fast
10 Red Dimming 0-255 0-100%
11
Green Dimming 0-255
0-100%
12
Blue Dimming
0-255
0-100%
13
LED1
0-31
Light off
32-255 LED all color dimming
14
LED2
0-31 Light off
32-255 LED all color dimming
…
……
……
…….
…
……
……
…….
29
LED17
0-31
Light off
32-255
LED all color dimming
30 LED18
0-31 Light off
32-255
LED all color dimming
31 Reset
0-249 Invalid
250-255 Machine reset (valid a�er 5
seconds)
