Algam Lighting Sunflower - Product Installation

PRODUCT INSTALLATION
Power supply
RIGGING
Attention! The installation must be carried out by qualified service personal only. Improper
installation can result in serious injuries and /or damage to property. Overhead rigging
required extensive experience! Working load limits should be respected, Certified
installation materials should be used, the installed device should be inspected regularly for
safety.
Before rigging make sure that
installation area can hold
the 10 times weight of device.
Clamp
Adjust angle
Safety rope
ATTACH SAFETY
CABLE HERE
SUNFLOWER
EFFET LED ROTATIF AVEC LASER 3B
WHEEL LED EFFECT WITH 3B LASER
VOLTAGE : 230V AC/50-60HZ
POWER RATING : 120W
IMPORTED BY/ IMPORTÉ PAR:
ALGAM, 2 RUE DE MILAN
44470 THOUARÉ-SUR-LOIRE
FRANCE
MADE IN CHINA
SUNFLOWER
ENTER
MENU
DMX INPUT
DMX OUTPUT
INTERLOCK
POWER INPUT: 100-240VAC 50/60HZ
FUSE: T 4A 250V
m
0.5
WARNING: SHOCK HAZARD - DO NOT OPEN
DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
ATTENTION: RISQUE DE CHOC ÉLÉCTRIQUE - NE PAS OUVRIR
TENIR A L’ABRIS DE LA PLUIE ET DE L’HUMIDITÉ
CAUTION
LASER
STATUS
IMPORTANT !
An «Interlock» connector cap is included in the box with this device. If you are not using system such as
an Emergency RED Button ( optional ... not included in this package) to shut down the LASER beam in
case of danger, you MUST connect this CAP to the INTERLOCK connector ( see (10) in previous page).
Without this CAP connector, the LASER beam will be turned off.
Emergency Red Button
( Optional, Not included with the product)
Interlock connector CAP
