Document 90-00066 Algo Communication Products Ltd (604) 454-3792
2014-02-20 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com
Page 2 www.algosolutions.com
CONTENTS
Important Safety Information ................................................................................. 4
About the 8128 Strobe ............................................................................................ 5
Common Applications .............................................................................................. 5
Quick Start .............................................................................................................. 6
What's Included ...................................................................................................... 7
Wiring Connections ................................................................................................. 8
Network Connection ................................................................................................. 8
Terminal Block Relay In ............................................................................................ 8
Terminal Block Relay Out .......................................................................................... 8
Terminal Block Reset ................................................................................................ 8
Web Interface Login ................................................................................................ 9
Basic Settings Tab - SIP ........................................................................................ 10
SIP Domain (Proxy Server) ..................................................................................... 10
SIP Extension ........................................................................................................ 10
Authentication ID ................................................................................................... 10
Authentication Password ......................................................................................... 10
Monitoring Mode .................................................................................................... 11
Activating 8128 Strobe Using Subscribe/Notify .......................................................... 11
Basic Settings Tab - Features ................................................................................ 12
Flash Patterns ....................................................................................................... 12
Flash Pattern Test .................................................................................................. 13
Cadence ............................................................................................................... 14
Relay Input Detection Mode .................................................................................... 14
Relay Input Action ................................................................................................. 14
Relay Output Mode ................................................................................................ 14
Multicast Overview ................................................................................................ 14
Multicast IP Addresses .......................................................................................... 15
Basic Settings Tab - Multicast Master Settings ...................................................... 16
Multicast Mode (Master Selected)............................................................................. 16
Master Zone .......................................................................................................... 16
Send Flash Pattern ................................................................................................. 17
Send 8180-Compatible Control Signal ...................................................................... 17
Zone Definitions .................................................................................................... 17
Synchronization ..................................................................................................... 17
Basic Settings - Multicast Slave Settings ............................................................... 18
Multicast Mode (Slave Selected) .............................................................................. 18
Slave Zones .......................................................................................................... 18
Zone Definitions .................................................................................................... 19
Advanced Settings - SIP ........................................................................................ 19
Outbound Proxy ..................................................................................................... 19
STUN Server ......................................................................................................... 19
Register Period (seconds) ....................................................................................... 20
Keep-alive Method ................................................................................................. 20
To Next Page
