AlgoLaser Alpha MK2 - Page 15

06/ 10
Assemble the X-Axis Assembly
Limit Switch Terminals
and
Interfaces
Insert the cable into the port of
the mainboard that matches the color of the cable.
Laser Module Cable
Air Pipe
Put the air pipe and main cable
through the hole under the Y-axis
12
