07/ 10
Fasten the belt locking screws
Use two M4*16 mm screws here
in conjunction with the left and right X-axis
tensioners to adjust the Y-axis belt.
Use M4*12 mm screws here
in conjunction with the X-axis tensioner
to adjust the X-axis belt.
Here use the left Y-axis tensioner fixing screw for locking.
Here use the right Y-axis tensioner fixing screw for locking.
13
