Step 7: Place E(X-Axis Assembly) on the top of the machine. NOTE: E(X-Axis Assembly) with the end of the Cable
Box should face B(Left Y-Axis Assembly). Then install the end with Cable Box of E(X-Axis Assembly) on the
Block of B(Left Y-Axis Assembly) with 2 screws. Install the other end of the E(X-Axis Assembly) on the Block
of C(Right Y-Axis Assembly) with 2 screws.
Screw type: M4X12 Screw.
M4X12 Screw
M4X12 Screw
Lever
Machine Assembly
Assemble the X-Axis Assembly
07/ 21
