Step 9: Pull down the Lever, and install the Laser Module on the Fixture, and then lift up the Lever to secure it in place.
X-Axis Assembly
Laser Module
Step 9: Finished
Pull it Down
Lift up
Machine Assembly
Mount Laser Module
