OWNER’S MANUAL
11
2) ENGINE OIL REPLACEMENT
3) AIR FILTER
1. Place the machine on a level surface
and warm up the engine for several
minutes. Then stop the engine.
2. Remove the oil filler cap.
3. Place an oil pan under the engine.
Remove the oil drain plug so that the
oil can be completely drained.
4. Check the oil drain plug, gasket, oil filler
cap and O-ring. If damaged replace.
5. Add engine oil to the upper level.
6. Reinstall the oil drain plug.
Maintaining an air cleaner in proper condition
is very important.
Dirt induced through improperly installed,
improperly serviced or inadequate elements
damages and wears out engines.
Keep the element always clean.
1. Take out the air cleaner, clean it well in
kerosenee and dry it.
BE SURE NO FOREIGN MATERIAL
ENTERS THE CRANKCASE.
CAUTION:
0
o
C 25
o
C
32
o
F 80
o
F
C SAE 10W B SAE #20 A SAE #30
or 10W-30 or 10W-30 or 10W-10
or 10W 40 or 10W-40 or 10W-40
