ALLECO 9750 - Symbols on the Display

42
Symbols on the display
1. Day of the week
2. Time and date
3. Selected menu/Current temp
(actual value) °C
4. Set temp (set point) °C
5. Selected control
6. Shows that a program is running
7. Lock symbol
8. Program
9. Event functions for personal settings
1
2
4
3
5
8
9
6
7
