ALLEN & HEATH SQ-7 User Manual

 113
Reference Guide V1.5.0
Mix Processing
Insert (Pre EQ/Comp)
Fully Patchable
Delay
Up to 682ms
GEQ
28 bands 31Hz-16kHz, +/-12dB Gain, Constant 1/3 oct,
DEEP options
PEQ
As Input PEQ
Compressor
As Input Compressor
FX
Internal FX
8 x RackExtra FX engine, Send>Return or Inserted (4
dedicated FX bus)
Types
SMR Reverb, Gated Reverb, Stereo Tap Delay, ADT, Blue
Chorus, Symphonic Chorus, Flanger, noo Phaser
8 dedicated Stereo FX returns
Fader, Pan, Mute, Routing to Mix/LR, 4-Band PEQ
Audio Tools
PAFL
PFL or stereo in-place AFL, 0 to -24dB Trim,
PAFL Delay Up to 682ms
Talkback
Dedicated input, Assignable to any mix and fully patchable,
Gain, Pad, 48V, 12dB/oct HPF
Signal Generator
Assignable to any channel, Sine/White/Pink/Bandpass
RTA’s
2x 31-Band 1/3 octave (Stereo) or 61-Band 1/6 octave
(Mono) 20-20kHz. PAFL/Selected Channel or Fixed Source
AMMs
Configuration
2x 24ch or 1x 48ch, freely assignable
Mode
Gain Sharing
Sidechain Filter HPF / LPF
12dB/octave 20Hz – 5kHz / 120Hz - 20kHz
Priority
-15dB to +15dB per channel
Add-ons
DEEP Preamps
Tube Stage
DEEP Compressors
Opto, 16T, 16VU, PeakLimiter76, Mighty
DEEP GEQ's
Proportional-Q, DiGi-GEQ, Hybrid
RackFX units
De-Esser, DynEQ4, MultiBD3, MultiBD4, Bucket Brigade,
Echo, Hypabass

ALLEN & HEATH SQ-7 Specifications

General

MIDI out	Yes
RJ-45 ports quantity	1
Channels quantity	48 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
DJ mixer	-
Product color	Black
Power consumption (typical)	- W

Weight and Dimensions

Depth	514.9 mm
Width	804 mm
Height	198 mm
Weight	17800 g
Package depth	685 mm
Package width	960 mm
Package height	360 mm
Package weight	21900 g
