ALLEN & HEATH SQ-7 User Manual

 112
Reference Guide V1.5.0
Input Processing
Source
CH1-48
Fully patchable
USB Global Source
SQ-Drive or USB-B Streaming
Polarity
Normal/Invert
Trim
-24 to +24dB
High Pass Filter
12/18/24dB per octave 20Hz – 2kHz
Insert (Pre EQ/Comp)
Fully Patchable
Delay
Up to 341ms
Gate
Patchable Sidechain
Sidechain filter
Hi-pass (20-5k), Band-pass (120-10k), Lo-pass (120-20k)
Threshold / Depth
-72dBu to +18dBu / 0 to 60dB
Attack / Hold / Release
50µs to 300ms / 10ms to 5s / 10ms to 1s
PEQ
4-Band fully parametric, 20-20kHz, +/-15dB
Band 1, Band 4
Selectable Shelving, Bell, HPF/LPF 12dB/octave
Band 2, Band 3
Bell
Bell Width
Variable Q, 1.5 to 1/9th octave
Compressor
Patchable Sidechain, DEEP options
Sidechain filter
Hi-pass (20-5k), band-pass (120-10k), Lo-pass (120-20k),
Q=1
Threshold / Ratio
-46dBu to 18dBu / 1:1 to infinity
Attack / Release
30µs to 300ms / 50ms to 2s
Knee
Soft/Hard
Detector response
Peak/RMS switchable
Parallel Path Compression
dry/wet -inf to 0dB
Channel Direct Out
Follow Fader, Mute, Mute Group, DCA (global all ch)
Source select
Post-Preamp, Post-HPF, Post-Gate, Insert Return,
Post-PEQ, Post-Comp, Post-Delay
trim -inf to 10dB per channel

ALLEN & HEATH SQ-7 Specifications

General

MIDI out	Yes
RJ-45 ports quantity	1
Channels quantity	48 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
DJ mixer	-
Product color	Black
Power consumption (typical)	- W

Weight and Dimensions

Depth	514.9 mm
Width	804 mm
Height	198 mm
Weight	17800 g
Package depth	685 mm
Package width	960 mm
Package height	360 mm
Package weight	21900 g
