ALLEN & HEATH SQ-7 User Manual

 26
Reference Guide V1.5.0
DEEP Preamp –
Preamps in the SQ itself and those in Remote Audio Units are accurate and
transparent, with fast transients and low THD. However, there are some situations
where alternative characteristics may be desirable. Using a DEEP preamp model
allows you to add these characteristics, with complete control, and none of the
associated limitations or reliability concerns of esoteric equipment.
• When in the channel ‘Preamp’ screen, press the ‘Library’ key to show the list of
preamp models.
• Select a preamp preset, then press the ‘Recall’ button to load it.
• Touch ‘On/Off’ to switch the preamp model on or off.
• Touch any on-screen parameter and adjust using the touchscreen rotary.
select preamp model
recall/load model
DEEP preamp controls

ALLEN & HEATH SQ-7 Specifications

General

MIDI out	Yes
RJ-45 ports quantity	1
Channels quantity	48 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
DJ mixer	-
Product color	Black
Power consumption (typical)	- W

Weight and Dimensions

Depth	514.9 mm
Width	804 mm
Height	198 mm
Weight	17800 g
Package depth	685 mm
Package width	960 mm
Package height	360 mm
Package weight	21900 g
