Allen-Bradley PowerFlex 20-750-20COMM - Page 65

Rockwell Automation Publication 750-IN001O-EN-P - October 2014 65
Lift and Mount the Drive Chapter 3
Figure 27 - Flange Mount, Frame 6
Dimensions are in millimeters and (inches).
208.4
(8.20)
346.4
(13.64)
308.0
(12.13)
665.5
(26.20)
162.0
(6.38)
24.0
(0.94)
262.0
(10.31)
362.0
(14.25)
462.0
(18.19)
562.0
(22.13)
600.0
(23.62)
624.0
(24.57)
26.0 (1.02)
91.0 (3.58)
193.0 (7.60)
258.0 (10.16)
225.5 (8.88)
284.0 (11.18)
24x: Ø6.4
(Ø0.25)
138.0
(5.43)
561.0 +2.0/-1.5
(22.09 +0.08/-0.06)
268.0 +2.0/-1.5
(10.60 +0.08/-0.06)
8.0
(0.30)
62.0
(2.44)
31.5
(1.24)
58.5 (2.30)
IMPORTANT
Must use Flange Adapter kit (20-750-FLNG4-F6) to meet enclosure rating.
