Allen-Bradley PowerFlex 20-750-S1 User Manual

100 Rockwell Automation Publication 750-IN001O-EN-P - October 2014
Chapter 3 Lift and Mount the Drive
Figure 61 - IP20, NEMA/UL Type 1, MCC Style Cabinet, Floor Mount Frame 9 Bottom Access
Enclosure Code B with P14 - 600 mm Deep Drive with Wiring Bay.
No. Description
➊ Power wiring conduit plates.
➋ Control wiring conduit plates.
300
(11.8)
531
(20.9)
669
(26.3)
900
(35.4)
1131
(44.5)
1269
(50.0)
ø18.0
(0.71)
542
(21.3)
43
(1.7)
69
(2.7)
500
(19.7)
460
(18.1)
344
(13.5)
➊
➊
➋
1500
(59.1)
1731
(68.1)
500
(19.7)
141
(5.6)
127
(5.0)
➊
➋
398
(15.7)
76
(3.0)
76
(3.0)
